Operation

13

13

Operation

USB operation

General information

  USB file systems supported: FAT32.

2.0 USB version is supported. Maximum
capacity 1 TB. For correct and satisfactory
operation, licensed USB devices of well-
known brands should be used with this unit.
Avoid using USB devices of unknown brands.
Playback of photos and music of only JPEG
and MP3 format is supported. The output
capability of the USB port is 500 mA.

• This unit supports playback of video files

with AVI, TS, MP4, MKV, MOV extension,
with video codecs H264/AVC, H263,
MPEG1/2/4 and audio codecs PCM,
MP3, AAC

.

  The above list of extensions and codecs

is for information only and is not a guarantee
that all files having the above extensions and
codecs should be read by this unit.

• Some AVI files cannot be played due to

their parameters and recording conditions.
Video files with AVI extension exceeding 2 GB
in size may be played partially.

  According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.

Warning:

 usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

File playback

Insert a USB into the USB jack. Press

SOURCE button, select Media option and
press ENTER button. The screen will show
USB playback menu.

USB


Music

Movie

• Video file playback: Select

Movie

item

and press ENTER button. Press cursor
buttons to select a file and press ENTER
button to start playback. During playback
press MENU button to show playback menu in
which you can select an operation by LEFT/
RIGHT cursor buttons and perform this
operation by pressing ENTER button. The
operations include Play/Pause, FB, FF, Prev.,
Next, Stop, Charset, Repeat Mode, AB Repeat
setting, Playlist, Info., Slow Forward, Step
Forward, Goto Time, Zoom In, Zoom Out,
Aspect Ratio, Move View. To exit video
playback press EXIT button.

• Photo file playback: Select


item

and press ENTER button. Press cursor buttons
to select a file and press ENTER button to start
playback. During playback press MENU button
to show playback menu in which you can select
an operation by LEFT/RIGHT cursor buttons
and perform this operation by pressing ENTER
button. The operations include: Play/
Pause,Prev.,Next,Stop,RepeatMode
Music

，

Playlist

，

Info.,Rotate(Clockwise),Rotate

(Counterclockwise),Zoom In,Zoom Out,Move
View. To exit photo playback press EXIT button.

• Music file playback: Select

Music

item and

press ENTER button. Press cursor buttons to
select a file and press ENTER button to start
playback. During playback press MENU button
to show playback menu in which you can
select an operation by LEFT/RIGHT cursor
buttons and perform this operation by pressing
ENTER button. The operations include Play/
Pause,FB, FF, Prev., Next, Stop, Repeat
Mode, Mute, Playlist, Info. and Goto Time. To
exit music playback press EXIT button.

CI Information

(only in DTV mode): This function enables

you to watch some encrypted services (pay
services). Please insert a CI card into the
