EN

14

English

Chapter 5 - Other information

Password in Parental Control

 - The default password is 1234. You can change it to

a new one.

 - The super password is 0423. If you forget your

code, enter the super password to override any

existing codes.

Troubleshooting

Please check the following list before requesting

service.

There is no picture or sound.

•  Make sure the power cord is properly inserted in the

power outlet.

•  Make sure the source type is set correctly.
•  Make sure the antenna is properly connected.
•  Make sure the volume is not set to minimum or the

sound is not set to mute.

•  Make sure the headphones are not connected.
•  The TV may be receiving a signal other than from

TV broadcasting stations.

Picture is not clear.

•  Make sure the antenna cable is properly connected.
•  Consider whether your TV signal is being properly

received.

•

Poor picture quality can occur due to a VHS

camera, camcorder, or other peripheral being

connected at the same time. Switch off one of the

other peripherals.

•  The ‘ghost’ or double image may be caused by

obstruction to the antenna due to high-rise buildings

or hills. Using a highly directional antenna may

improve the picture quality.

•  The horizontal dotted lines shown on the pictures

may be caused by electrical interference, e.g., hair

dryer, nearby neon lights, etc. Turn off or remove

these.

Picture is too dark, too light or tinted.

•  Check the colour adjustment.
•  Check the brightness setting.
•  Check the sharpness function.

Remote control does not work.

•  Check the batteries of the remote control.
•  Make sure the remote sensor window on the TV

front is not under strong fluorescent lighting.

•  Try to clean the remote sensor window on the TV

front with a soft cloth.

If the above suggestions do not solve your technical

issue, please refer to the warranty card for service

information.

Operating Conditions

Temperature 5°C–35°C (41°F–

95°F)

Humidity 20–

75% (non-condensing)

Storage Conditions

Temperature -15°C–45°C (5°F–

113°F)

Humidity 10–

90% (non-condensing)

Radio Information

•  2.4G Wi-Fi transmitter frequency range: 2400–

2483.5MHz

•

2.4G Wi-Fi transmitter power: 16dBm (+4/-5dB)

•  Bluetooth® transmitter frequency range: 2402–

2480MHz

•  Bluetooth®

 transmitter power: 3dBm (+5/-3dB)

•

DVB-T/T2/C tuner frequency range: 50.5–858MHz

•

DVB-S/S2 tuner frequency range: 950–2150MHz

OSS Notice

This product uses the GPL (Version 2 and 3) and

LGPL (version 2.1) and MPL (version 1.1).

To send inquires and requests for questions regarding

open source, contact nearest TCL office.

This product uses some software programs which are

distributed under the Independent JPEG Group.

This product uses some software programs which are

distributed under the libpng Project.

This product uses some software programs which are

distributed under the Freetype Project.

This product uses some software programs which are

distributed under the zlib Project.

This product uses some software programs (libxml2,

curl, expat, c-areas) which are distributed under the

MIT.
This product uses CyberLink for C which is distributed

under the Open Source Project.

This product uses opensl, xerces which is distributed

under the Apach License Project.
GPL software: Linux Kernel, glib, libiconv, gcc libgcc,

gcc libstdc++, u-Boot loader, ffmepg, util-linux-ng,

e2fsprogs, wget, iptables

LGPL software: DFB (DirectFB), gstreamer, gst-

plugins-base, gst-plugins-good, gst-plugins-bad, gst-

plugins-ugly, gst-ffmpeg, glibc, wpa_supplicant

BSD software: webp, mng, uriparser
GNU software: dosfstools

[Legal Statement] of TCL - manufacturer of this

TV set

Due to the various capabilities of products featuring

the SmartTV - Services, as well as limitations in the

available content, certain features, applications, and

services may not be available on all devices or in

all territories. Some features on SmartTV may also
