Transporting

• Before transporting the TV set, disconnect all cables.
• Two or more people are needed to transport a large TV set.
• When transporting the TV set by hand, hold it as shown below.

Do not put stress on the panel and the frame around the screen.

• When transporting the TV set, do not subject it to jolts or

excessive vibration.

• When transporting the TV set for repairs or when moving, pack

it using the original carton and packing material.

Topple prevention

Precautions to Protect the Screen from
Damage

Image retention

OLED TV’s are susceptible to image retention (burn-in) due to the
characteristics of the materials used. Image retention may occur if
images are displayed in the same location on the screen
repeatedly or over extended periods of time. This is not a
malfunction of the TV. Avoid displaying images that may cause
image retention.

The following are examples of images that may
cause image retention:

• Content with black bars either on the top and bottom and/or

the left and right sides of the screen. (for example, Letterboxed,
4:3 screen, Standard definition)

• Static images such as photos.
• Video games that might have static content in some part of the

screen.

• On-screen menus, programme guides, channel logos etc.
• Static content from applications.
• On-screen tickers, such as those used for news and headlines.

To reduce the risk of image retention:

• Sony recommends that you turn off the TV normally by pressing

the power button on the remote control or the TV.

• Fill the screen by changing [Wide mode] to eliminate the black

bars. Select [Wide mode] other than [Normal].

• Turn off the OSD (On Screen Display) by pressing the

/

(Info/Text reveal) button, and turn off the menus from
connected equipment. For details, refer to the instruction
manuals for the connected equipment.

• Avoid displaying static images with bright colours (including

white), clocks or logos on any portion of the screen.

• Set the picture settings based on the ambient conditions. The

Standard Picture is recommended for home use and when
viewing content that often displays the station logos, etc.

The TV has following features to help reduce/prevent image
retention.

Panel refresh

A panel refresh will adjust the panel uniformity. Panel refresh can
be performed and should only be used when image retention is
very noticeable.

Caution:
• The Panel refresh function may affect the panel. Do not perform

Panel refresh more than once a year as it may affect the usable
life of the panel.

• Panel refresh takes about one hour to complete.
• A white line may be displayed on the screen during the Panel

refresh, this is not a malfunction of the TV.

• Panel refresh will only work when the room temperature is

between 10 ºC and 40 ºC.

Pixel shift

Automatically moves the image on the screen to prevent image
retention.

Other feature

The screen brightness is automatically reduced when displaying
still images, clocks, bright colours or logos etc.

• When handling or mounting the TV

set, do not lay down the TV.

2

4

1

3

10 mm – 14 mm

M6 screw (not supplied)

Screw (not supplied)

Cord (not
supplied)

1.5 N·m
{15 kgf·cm}

Protecting the TV Screen (OLED TV)
