17

English

Operating conditions

Temperature

0 °C - 35 °C

Humidity

20 % - 80 % RH (non-condensing)

Built-in wireless LAN

Standard compliance and Frequency range

*

2

IEEE802.11a/n
5.180 GHz - 5.320 GHz, 5.500 GHz - 5.580 GHz,
5.660 GHz - 5.700 GHz
IEEE802.11b/g/n
2.412 GHz - 2.472 GHz

Security

WPA2-PSK (TKIP/AES)
WPA-PSK (TKIP/AES)
WEP (64 bit/128 bit)

*

1:

when the TV is turned off with the remote control and
no function is active

*

2:

The frequency and channel differ depending on the
country. Follow the regulations of your country for
the frequency range.

Note

●

Design and Specifications are subject to change
without notice. Mass and Dimensions shown are
approximate.

●

For the information of the open source software, refer
to [eHELP] (Support > Licence).

HDMI 1 / 2 input

TYPE A Connectors
HDMI1:  Content Type
HDMI2:  Content Type, Audio Return Channel

●

This TV supports “HDAVI Control 5” function.

Card slot

Common Interface slot (complies with CI Plus) × 1

ETHERNET

RJ45, IEEE802.3 10BASE-T / 100BASE-TX

USB Port

DC 5 V, Max. 500 mA [Hi-Speed USB (USB 2.0)]

DIGITAL AUDIO output

PCM / Dolby Digital / DTS, Fibre optic

Receiving systems / Band name

Check the latest information on the available services at
the following website. (English only)
http://panasonic.net/viera/support

DVB-C

Digital cable services (MPEG2 and MPEG4-
AVC(H.264))

DVB-T / T2

Digital terrestrial services (MPEG2 and MPEG4-
AVC(H.264))

PAL D, K
SECAM D, K

VHF R1 - R2
VHF R3 - R5
VHF R6 - R12
UHF E21 - E69

PAL 525/60

Playback of NTSC tape from some PAL Video
recorders (VCR)

M.NTSC

Playback from M.NTSC Video recorders (VCR)

NTSC (AV input only)

Playback from NTSC Video recorders (VCR)

Aerial input

VHF / UHF
