background image

5

PRODUCT SET, PIC. B

Dehydrator. ......................................................... 1pc.

Tray for crumb  ................................................... 1pc.

Mesh tray for drying  .......................................... 5 pcs.

Warranty card ......................................................... 1pc.

Instructions manual ................................................ 1pc.

Continuous operation time should not ex-

ceed 99 hours. After 99 hours, turn off the de-

vice, unplug it and let it cool down for 1 hour.

UTILIZATION

Ingredients

Preparation

Cooking

time

Notes

Drying (optimal temperature 40-50°С)

General recommendations:

Preparation includes: sorting, washing, drying, cutting, grinding, pre-soaking, marinating or

cooking. Products can be dried with peel. Exceptions are the products that have edible skins - for example, pineapple,

kiwi, papaya, coconut, bananas, turnips and sweet potatoes. Products for drying must not be spoiled. Particular attention

is paid to the quality of raw pork, poultry and fish in order to avoid food poisoning. To preserve the color of the products

it is recommended to pre-soak them in the lemon juice or solution of ascorbic acid. It is recommended before the

dehydrogenation to scald with boiling water or blanch some vegetables, such as beans, corn, peas or broccoli. Raw

vegetables will not be stored for a long time, heat treatment will prolong their life. Check the quality of the dried products

when stored. Spoiled, moldy products must be utilized. It is recommended to record information on the duration of

dehydration of the products for further use.

Apples (pear, quince,

etc.)

Cut into thin slices, remove the core

8-15 hours

Soft, bendable slices

Apricots (peaches,

nectarines, etc.)

Cut in halves, remove the seed, place with cut side up

20-30 hours

Soft, bendable halves

Bananas (avocados,

persimmons, etc.)

Cut in thin slices or plates

6-10 hours

Hard slices or plates

Cherry, etc.

Remove the seed, place with cut side up

12-48 hours

Resembles raisins

Blueberries

(cranberries)

Select same sized berries

10-20 hours

Melon (watermelon,

pumpkin, etc.)

Peel, remove seeds, cut in big slices

10-48 hours

Soft, bendable slices

CONTROL PANEL, Pic. C-7

 – use ON/OFF button to turn off and on the device

 – use the button  to change the temperature setting or

cooking time

 – use buttons to adjust temperature/time

 – cooking time indication
 – temperature setting indication

Display -

indication of time/temperature of dehydration

ELEMENTS OF DESIGN, PIc. С

Door

Magnetic lock

Viewing window

Grooves for mesh

Fan

Ventilation openings

Control panel

Display

4
5
6
7
8

Before first use,

wipe the body of the device with a damp

and soft cloth inside and out. Wash the tray and meshes

with warm water and some dishwashing liquid. Wipe

everything dry.

Before assembling or disassembling the

device, make sure that it is unplugged.

Turn on the empty device for 15 minutes, setting the

maximum temperature to 80°C to remove odors from the

new device. Ventilate the room. Let the device cool down.

Order of operation:

1.  Prepare the required ingredients for dehydration. Cut

them and fill the trays.

2.

 Place the trays with food into the device.

3.

Install the crumb tray.

4.

 Turn on the device by pressing    button. The default

cooking time is 8 hours, the cooking temperature is

35°C. Temperature adjustment range from 30°C to 80°C;

time adjustment range from 1 h to 99 h.

5.   Press

 button, to select the setting of the cooking time

or temperature.

6.  With the help of

 buttons  set cooking time/

temperature.

7.   5 seconds after setting the time and temperature, the

device will automatically start the program. To cancel the

cooking program press the button  .

NOTE:

 Do not forget to unplug the device after use.

PREPARATION RECOMMENDATIONS

Time and temperature are for reference only. Dehy

-

dration time may vary depending on the thickness of

the slices, humidity and temperature in the room, and

personal taste.

Set the temperature to a higher setting to dry ingredi

-

ents quickly. To preserve the beneficial properties of the

ingredients, set the temperature to no more than 45°С.
