Braun J700 - Инструкция по эксплуатации - Страница 8

9

11  Juice jug lid
12 Foam

separator

13 Juice

jug

14 Cord

storage

15 Cleaning

brush

Before using for the first time, wash the detachable
juicer parts (see «Disassembling» and «Cleaning»).

Start lock / Safety system

The appliance can only be switched on when the
juice collector (5) has been inserted and the lid is
securely locked with the clamps (3). When the
clamps are released while the motor is running, the
motor stops within 3 seconds.

Assembling

1.  Assemble the juice spout (10a/10b) to the juice

collector (fig. a). Slightly press together the sides
of the juice spout with thumb and forefinger at
the check marks.

2.  Put the juice collector (5) on the motor part (1)

(fig. b).

3.  Place the filter (6) onto the juice collector and

press it down until it locks on the motor coupling
(fig b).

4.  Slide the pulp container (4) to the rear part of the

motor unit until it connects. Be sure it snaps into
place (fig. c).

5.  Attach the lid (7) (fig. c). Attach both clamps to

the lugs on the lid and push down firmly until you
hear them snap into place (fig. d).

6.  Make sure the juice jug (13) is placed underneath

the juice spout (10) (fig. e). Capacity: 1250 ml.

The juice collector comes with a foam separator
(12) to help keeping the juice almost foam-free. If it
is not required simply remove the foam separator.

Extracting juice

•

Important: Use only well ripened fruits otherwise
the filter (6) may be clogged up.

•

Before use, always unwind the power cord
completely from the cord storage (14).

•

Fruits/vegetables need to be washed if they will
be processed unpeeled.

•

Maximum operation time / amount at a time:
15 minutes / 5 kg.
Let appliance cool down sufficiently afterwards.

Type of fruits/
vegetables

Preparation

Pro-
cessing

Hard fruits/
vegetables e.g.
apples, pears,
carrots, beets

Remove uneatable
peel
Process seed fruits
with cores

Position II

Leaf vegetables
e.g. cabbage,
spinach or herbs

Roll up leaves
together tightly
before processing

Position II

Soft fruits/
vegetables e.g.
citrus fruits, kiwis

Remove uneatable
peel

Position I

Grapes

Cut off main stems

Stone fruits e.g.
plums, peaches

Remove stones

Melons

Peel and cut into
pieces to fit the
filling shaft

Tomatoes,
cucumbers,
raspberries

No further
preparation needed

Berries

Only suitable in
mixed juices

Position I

Rhubarb, fruits that contain starch
(bananas, mangoes, papayas,
avocados and figs), very hard and
fibrous fruits or vegetables

Not
suitable

•

Put fruits or vegetables into the filling shaft (8)
(fig. e).

•

Turn the switch (2) to position «I» or «II»:

•

Press slightly with the pusher (9) (fig. f). Add
more fruits or vegetables while the motor is
running.

•

The amount of juice you extract depends on the
nature of the fruits and vegetables.

•

Fruit and vegetable juices contain valuable
vitamins and minerals, which quickly deteriorate
when they come into contact with oxygen or light.
Drink juice fresh – right after it has been
extracted.

Emptying the pulp container and filter

Pulp container (4):  As soon as the pulp container
looks full turn off the appliance, unplug it and empty
the pulp container.
Filter (6): If the juice suddenly becomes much
thicker, if larger amounts of pulp get stuck between
filter and lid and/or if you can hear the motor speed
slow down, the filter and juice collector must be
emptied and cleaned (see «Disassembling »).
Empty the pulp container and assemble the appli-
ance again.

Drip stop feature

(only model J700/J500)

When the juice spout (10a) is in a tilted position it
functions as a drip stop and collects the dripping
juice:
Turn the appliance off, wait for a few seconds until
the juice only drips from the appliance. Then push
the spout (10a) to the tilted position (fig. g).

Disassembling

1.  Switch off the appliance by turning the switch (2)

to position « O » and unplug it (fig. h).
