7

UA

БУДОВА ПРИСТРОЮ

 Diagram of name and position of main components

1

 OPERATING INSTRUCTIONS

4

1. Prepare your fruits and vegetables by washing them thoroughly and

    peeling off those that need the skin removed.

2. Your juicer features an extra wide chute and thus most fruits and

    vegetables such as small apples, carrots, pears and others will not need

    to be cut into small pieces if they fit in the chute.

3. Make sure your juice extractor is properly assembled. Please follow the

    instructions from the section “Before Using Your Juice Extractor.”

4. Ensure the juice extractor and its accessories are clean by following the

    cleaning and maintenance section of this manual.

5. Place the juicer jug or other container/glass you may wish to use to

    collect the juice under the spout and make sure the residue barrel is in

    place prior to begin juicing. Do not allow the residue barrel to overfill as

    this may cause the unit to stall.

6. Plug the power cord into an electrical outlet and turn the power on “I”.

7. Once the juicer is on, place the fruits and vegetables into the feeding

    tube and use pushing bar to drive them down slowly. In order to extract

    the maximum amount of juice, it is important to push the pushing bar

    slowly.

8. The juice extractor will separate the juice and residue in the juicer jug

    and barrel automatically while you are juicing.

Note: Never use hand or fingers to push food down into the feeding

tube or clean the feeding tube, always use the pushing bar provided.

 OPERATION TIME

This juice extractor is designed with rotation switches of O grading, I

grading, II grading (O for stop, I for weak grading, II for strong grading). For

juicing hard fruits, select strong grading II, after operating for 1 min, stop for

1 min, then use again. After above operation is performed for three times,

stop for 15 min, do not operate until the motor is cool down. In this way,

service life of this machine would be prolonged and it will serve you more

efficiently.

1

2

3

4

5

6

7

1. Pushing bar
2.Transparent cover
3. Juicing net
4. Middle ring

5. Handle
6.  Main machine
7. Juicer jug

❶

 Штовхач

❷

 Прозора кришка

       із завантажувальним отвором

❸

 Фільтр

❹

 Збирач соку

❺

 Ручка

❻

 Моторний блок

❼

 Чаша для соку
