Navigating the Setup Menu
4
In this chapter, we will take a look at the menu system of the
SCC-C4207(P),C4307(P). First, we will take a look at the
structure of the Setup Menu and then describe the functions
of each menu item in the menu.
Structure of the Setup Menu
OFF/ON...
ALC.../WDR.../MANU...
OFF/1/100 ~ 1/10K/AUTO X2...~X160...
OFF/LOW/HIGH(AGC)
S.SLOW/SLOW/NORMAL/
FAST/F.FAST(MOTION)
ATW1/ATW2/AWC/MANU...
AF/MF/ONEAF
OFF/ON...
COLOR.../BW.../AUTO.../EXT...
OFF/ON...
PRIVACY
COLOR/BW
MOTION DET
FOCUS MODE
WHITE BAL
AGC/MOTION
SHUTTER
IRIS
CAMERA ID
...
POSI/NEGA
+/-
DIS
OFF
REVERSE
OFF
DETAIL
( 1)-I-
Y-LEVEL
( 0)|--------
C-LEVEL
( 0)|--------
OTHER SET
...
LANGUAGE/CTRL TYPE/
RS-485/SYSTEM INFO/
V-SYNC(
❖
)
RET
...
EXIT
PRESET
SPECIAL
❖
V-SYNC menu is only available in SCC-C4307.
Press the
ENTER
button.
Press the
ENTER
button.
CAMERA ID
OFF
IRIS ALC...
SHUTTER OFF
AGC LOW
WHITE BAL
ATW
FOCUS MODE
AF
MOTION DET
OFF
COLOR/BW AUTO...
PRIVACY ...
SPECIAL
...
PRESET ...
EXIT QUIT
(IRIS/ALC)
BLC OFF
LEVEL (00) ----I----
RET
❙
CAMERA ID
In the CAMERA ID menu, you may designate the CAMERA
ID to be displayed in the monitor connected to a camera. Set
the CAMERA ID menu to ON... and press [ENTER] and the
CAMERA ID setup submenu will appear. The CAMERA ID
may be created by up to 20 digits by using alphabets,
numbers, and some special texts served by the submenu
screen. You may locate the designated CAMERA ID on your
own by using the LOCATION... submenu.
❙
IRIS
✔
ALC
Select ALC... from the IRIS menu and press [ENTER]
and the BLC(Back Light Compensation) setup submenu
will appear. If you use a general camera to photograph a
subject under backlight or bright illumination, the subject
will be shown dark on the monitor due to the backlight.
BLC(Back Light Compensation) is used to prevent such a
backlight problem to secure distinct images under bright
illumination. Using the [Left, Right] keys, you can set up
BOTTOM…, TOP…, LEFT…, RIGHT…, CENTER… 5
preset areas and the USER…function that can directly
set the areas. For example, for the items in the BLC
menu, you can confirm the preset BOTTOM area by
pressing [ENTER] key in the BOTTOM… status.
CAMERA ID
ON...
IRIS
ALC...
SHUTTER
OFF
AGC
LOW
WHITE BAL
ATW1
FOCUS MODE
AF
MOTION DET
OFF
COLOR/BW
AUTO...
PRIVACY
OFF
SPECIAL
...
PRESET
...
EXIT
QUIT
(CAMERA ID)
A B C D E F G H I J K L
M N O P Q R S T U V W X
Y Z 0 1 2 3 4 5 6 7 8 9
.
; !
- + * () /
SP
❿❿☎☎☎☎➛➛
SP
LOCATION...
RET
......................
