QuickSpecs
HPE ProLiant DL380 Gen10 Server
Technical Specifications
Page 45
System Unit
Dimensions
8.73 x 44.55 x 67.94 cm
3.44 x 17.54 x 26.75 in
SFF Drives:
8.73 x 44.55 x 73.02 cm
3.44 x 17.54 x 28.75 in
LFF Drives:
Weight
(approximate)
14.9 kg
32.75 lb
Minimum: 8 SFF chassis with 1x SFF HDD and 7 HDD blanks, 2x Drive
Bay blanks, 1x processor including standard heatsink, 1x power supply
(plus blank), 1x Smart Array, 1x Riser installed, cables for the above)
23.6 kg
51.5 lb
Maximum: 12 LFF hard drives (no rear drives), 2x processors, 2x power
supplies, 1x Smart Array, 2x Risers installed)
Input Requirements
(per power supply)
Rated Line Voltage
100 to 120 VAC
200 to 240 VAC
BTU Rating
Maximum
For 800W Power Supply: 3207 BTU/hr (at 100 VAC), 3071 BTU/hr (at
200 VAC), 3112 BTU/hr (at 240 VAC) for China Only
For 500W Power Supply: 1979 BTU/hr (at 100 VAC), 1911 BTU/hr (at
200 VAC), 1965 BTU/hr (at 240 VAC) for China Only
Power Supply Output
(per power supply)
Rated Steady-State Power For 1400W Power Supply: 1400W (at 240 VAC), 1400W (at 240 VAC)
For 800W Power Supply: 800W (at 100 VAC), 800W (at 240 VAC),
800W (at 240 VAC) input for China only
For 500W Power Supply: 500W (at 100 VAC), 500W (at 240 VAC),
500W (at 240 VAC) input for China only
Maximum Peak Power
For 1400W Power Supply: 1400W (at 200 to 240 1VAC), 1400W (at
240 VAC) input for China only
For 800W Power Supply: 800W (at 100 to 127 VAC), 800W (at 200 to
240 1VAC), 800W (at 240 VAC) input for China only
For 500W Power Supply: 500W (at 100 to 127 VAC), 500W (at 200 to
240 VAC), 500W (at 240 VAC) input for China only
System Inlet Temperature
Standard Operating
Temperature
10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C
per every 305 m (1.8°F per every 1000 ft) above sea level to a
maximum of 3050 m (10,000 ft), no direct sustained sunlight.
Maximum rate of change is 20°C/hr (36°F/hr). The upper limit and rate
of change may be limited by the type and number of options installed.
System performance during standard operating support may be
reduced if operating with a fan fault or above 30°C (86°F).
Extended Ambient
Operating Temperature
For approved hardware configurations, the supported system inlet
range is extended to be: 5° to 10°C (41° to 50°F) and 35° to 40°C (95°
to 104°F) at sea level with an altitude derating of 1.0°C per every 175
m (1.8°F per every 574 ft) above 900 m (2953 ft) to a maximum of
3050 m (10,000 ft). The approved hardware configurations for this
system are listed at the URL:
http://www.hpe.com/servers/ashrae
For approved hardware configurations, the supported system inlet
range is extended to be: 40° to 45°C (104° to 113°F) at sea level with
an altitude derating of 1.0°C per every 125 m (1.8°F per every 410 ft)
above 900 m (2953 ft) to a maximum of 3050 m (10,000 ft). The
approved hardware configurations for this system are listed at the URL:
http://www.hpe.com/servers/ashrae
