QuickSpecs
HPE ProLiant DL380 Gen10 Server
Configuration Information - Factory Integrated Models
Page 20
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered,
Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales
representative for information on configurable product offerings and requirements.
1. Factory Integrated Models must start with a CTO Server.
2. FIO indicates that this option is only available as a factory installable option.
3.
All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard drives
ordered with the server.
4. Some options may not be integrated at the factory. Contact your local sales representative for additional information.
Step 1: Base Configuration (choose one of the following configurable models)
CTO Server
HPE ProLiant DL380
Gen10 8 LFF CTO Server
HPE ProLiant DL380
Gen10 12 LFF CTO
Server
HPE ProLiant DL380
Gen10 8 SFF CTO Server
HPE ProLiant DL380
Gen10 24 SFF CTO
Server
SKU Number
868706-B21
868705-B21
868703-B21
868704-B21
TAA SKU
875784-B21
875785-B21
875782-B21
875783-B21
Processor
Not included as standard
Not included as standard
Not included as standard
Not included as standard
DIMM Slots
24-DIMM slots
24-DIMM slots
24-DIMM slots
24-DIMM slots
Storage
Controller
Embedded SW RAID with 14 SATA ports, choice of HPE modular Smart Array and PCIe plug-in controller
PCIe
Three standard in primary riser (with dual M.2 support)
Drive Cage -
included
8 LFF
12 LFF
8 SFF
24 SFF
Network
Controller
Embedded 4x1GbE with optional HPe FlexLOM and optional Standup card
Fans
4-Standard
6-High Performance
4-Standard
6-Performance
Management
HPE iLO with Intelligent Provisioning (standard), iLO Advances and OneView (optional)
USB
1x 3.0 standard plus iLo
front service port
None as standard
1x 3.0 standard plus iLo
front service port
1x 3.0 standard plus iLo
front service port
NOTE:
HPE offers multiple Trade Agreement Act (TAA) compliant configurations to meet the needs of US Federal Government
customers. These products are either manufactured or substantially transformed in a designated country. TAA compliance is
only provided when HPE options are included as part of factory integrated orders (CTO).
NOTE:
The HPE ProLiant DL380 Gen10 12 LFF CTO Server ships with the cable required for the P816i-a installation.
CTO Server
8 SFF CTO Chassis
24 SFF CTO Chassis
8 LFF CTO Chassis
12 LFF CTO Chassis
Included Drive Cage
8 SFF SAS/SATA
3x 8 SFF SAS/SATA
8 LFF + UMB
12 LFF Chassis
Additional drive cages
Universal Media Bay
1 Optional
Not available
1 Included
Not available
ODD
1 Optional with UMB
Not available
1 Optional
Not available
8 SFF Drive Cage
Up to 2 Optional
Not available
Not available
Not available
8 NVME/SAS Bay
Up to 3 Optional
Not available
Not available
Not available
8 NVME Cage
Up to 3 Optional
Not available
Not available
Not available
2 SFF SAS/SATA (Front)
1 Optional with UMB
Not available
1 Optional
Not available
2 SFF SAS/SATA (Rear)
Not available
Up to 3 Optional
Not available
Up to 3 Optional
2 NVMe (Front)
1 Optional with UMB
Not available
1 Optional
Not available
4 LFF Mid-plane
Not available
Not available
1 Optional
1 Optional
3 LFF Rear
Not available
Not available
1 Optional
1 Optional
