YDP-131/YDP-213

   èËÎÓÊÂÌËÂ

40

ормат MIDI-данных

ÖÒÎË ‚˚ ÛÊ Á̇ÍÓÏ˚ Ò MIDI-ËÌÚÂÙÂÈÒÓÏ ËÎË ÛÔ‡‚ÎflÂÚ ÏÛÁ˚͇θÌ˚Ï Ó·ÓÛ‰Ó‚‡ÌËÂÏ Ò ÔÓÏÓ˘¸˛ ÒÓÁ‰‡‚‡ÂÏ˚ı ÍÓÏÔ¸˛ÚÂÓÏ

MIDI-ÒÓÓ·˘ÂÌËÈ, ÚÓ ˝ÚÓÚ ‡Á‰ÂÎ ÔÓÏÓÊÂÚ ‚‡Ï ÔË ‡·ÓÚÂ Ò ËÌÒÚÛÏÂÌÚÓÏ.

1. NOTE ON/OFF

Data format: [9nH] -> [kk] -> [vv]

9nH = Note ON/OFF event (n = channel number)
kk =

Note number (Transmit: 09H ~ 78H = A-2 ~ C8 /
Receive: 00H ~ 7FH = C-2 ~ G8)

vv =

Velocity (Key ON = 01H ~ 7FH, Key OFF = 00H)

Data format: [8nH] -> [kk] -> [vv] (reception only)

8nH = Note OFF event (n = channel number)
kk =

Note number: 00H ~ 7FH = C-2 ~ G8)

vv =

Velocity

2. CONTROL CHANGE

Data format: [BnH] -> [cc] -> [vv]

BnH = Control change (n = channel number)
cc =

Control number

vv =

Data Range

(1) Bank Select

ccH

Parameter

Data Range (vvH)

00H

Bank Select MSB

00H:Normal

20H

Bank Select LSB

00H...7FH

Ç˚·Ó ·‡Ì͇ Ì ÔÓËÁ‚Ó‰ËÚÒfl ‰Ó ÔÓÎÛ˜ÂÌËfl ÒÎÂ‰Û˛˘Â„Ó ÒÓÓ·˘ÂÌËfl
Program Change.

(2) Main Volume

ccH

Parameter

Data Range (vvH)

07H

Volume MSB

00H...7FH

(3) Expression (reception only)

ccH

Parameter

Data Range (vvH)

0BH

Expression MSB

00H...7FH

(4) Damper

ccH

Parameter

Data Range (vvH)

40H

Damper MSB

00H...7FH

(5) Sostenuto

ccH

Parameter

Data Range (vvH)

42H

Sostenuto

00H-3FH:off, 40H-7FH:on

(6) Soft Pedal

ccH

Parameter

Data Range (vvH)

43H

Soft Pedal

00H-3FH:off, 40H-7FH:on

(7) Effect1 Depth (Reverb Send Level)

ccH

Parameter

Data Range (vvH)

5BH

Effect1 Depth

00H...7FH

Adjusts the reverb send level.

(8) Effect4 Depth (Variation Effect Send Level)

ccH

Parameter

Data Range (vvH)

5EH

Effect4 Depth

00H...7FH

(9) RPN

65H

RPN

MSB

64H

RPN

LSB

06H

Data Entry

MSB

26H

Data Entry

LSB

60H

Data

Increment

61H

Data

Decrement

* Parameters that are controllable with RPN
• Coarse Tune
• Fine Tune
• Pitch Bend Range

3. MODE MESSAGES

Data format: [BnH] -> [cc] -> [vv]

BnH = Control event (n = channel number)
cc =

Control number

vv =

Data Range

(1) All Sound Off

ccH

Parameter

Data Range (vvH)

78H

All Sound Off

00H

(2) Reset All Controllers

ccH

Parameter

Data Range (vvH)

79H

Reset All Controllers

00H

Resets controllers as follows.
Controller

Value

Expression

127 (max)

Damper Pedal

0 (off)

Sostenuto

0 (off)

Soft Pedal

0 (off)

(3) Local Control (reception only)

ccH

Parameter

Data Range (vvH)

7AH

Local Control

00H (off), 7FH (on)

(4) All Notes Off

ccH

Parameter

Data Range (vvH)

7BH

All Notes Off

00H

ÇõäãûóÄÖí ‚Ò ÇäãûóÖççõÖ ÌÓÚ˚ ̇ Û͇Á‡ÌÌÓÏ Í‡Ì‡ÎÂ. ÇÒ
ÌÓÚ˚, Û‰ÂÊË‚‡ÂÏ˚ Ò‰ÌÂÈ ËÎË Ô‡‚ÓÈ Ô‰‡ÎflÏË, ÔÓ‰ÓÎʇڠ
Á‚Û˜‡Ú¸, ÔÓ͇ Ô‰‡Î¸ Ì ·Û‰ÂÚ ÓÚÔÛ˘Â̇.

(5) Omni Off (reception only)

ccH

Parameter

Data Range (vvH)

7CH

Omni Off

00H

Same processing as for All Notes Off.

(6) Omni On (reception only)

ccH

Parameter

Data Range (vvH)

7DH

Omni On

00H

Same processing as for All Notes Off.

(7) Mono (reception only)

ccH

Parameter

Data Range (vvH)

7EH

Mono

00H

Same processing as for All Sound Off.

(8) Poly (reception only)

ccH

Parameter

Data Range (vvH)

7FH

Poly

00H

Same processing as for All Sound Off.

• ÖÒÎË ÙÛÌ͈Ëfl «Control Change» ÇõäãûóÖçÄ, ÒÓÓ·˘ÂÌËfl Control

Change Ì Ô‰‡˛ÚÒfl Ë Ì ÔËÌËχ˛ÚÒfl.

• ëÓÓ·˘ÂÌËfl Local on/off, OMNI on/off Ì Ô‰‡˛ÚÒfl. (èË Ô‰‡˜Â

ÒÓÓ·˘ÂÌËfl «All Note Off» Ô‰ÓÒÚ‡‚ÎflÂÚÒfl ÒÓÓÚ‚ÂÚÒÚ‚Û˛˘ËÈ ÌÓÏ
‚˚Íβ˜ÂÌÌÓÈ ÌÓÚ˚.)

• èË ÔÓÎÛ˜ÂÌËË ·‡Ì͇ ÚÂÏ·Ó‚ MSB/LSB ÌÓÏ ı‡ÌËÚÒfl ‚Ó

‚ÌÛÚÂÌÌÂÏ ·ÛÙ ÌÂÁ‡‚ËÒËÏÓ ÓÚ ÔÓfl‰Í‡ ÔÓÎÛ˜ÂÌËfl, Á‡ÚÂÏ
ÒÓı‡ÌÂÌÌÓ Á̇˜ÂÌË ËÒÔÓθÁÛÂÚÒfl ‰Îfl ‚˚·Ó‡ ÌÛÊÌÓ„Ó ÚÂÏ·‡ ÔË
ÔÓÎÛ˜ÂÌËË ÒÓÓ·˘ÂÌËfl Program Change.

• êÂÊËÏ Poly ‚Ò„‰‡ ‚Íβ˜ÂÌ. ùÚÓÚ ÂÊËÏ Ì ËÁÏÂÌflÂÚÒfl ÔË

ÔÓÎÛ˜ÂÌËË ËÌÒÚÛÏÂÌÚÓÏ ÒÓÓ·˘ÂÌËfl MONO/POLY.
