7

EN

TOOLS PARTS OVERVIEW

TOOL PARTS OVERVIEW

1.  Chuck

2.  Left/right rotation switch L/R

3.  On/off button

4.  Variable speed dial

5.  Lock-on button

6.  Auxiliary handle

7.  Depth gauge

8.  Changeover switch

9.  Gear selection switch

OPERATION

SWITCHING ON - SWITCHING OFF

Brief activation

Switching on: Press ON/OFF switch 3.

Switching off: Release ON/OFF switch 3.

Continuous operation

Switching on: Press ON/OFF switch 3 and in pressed position lock it by button 5.

Switching off: Press ON/OFF switch 3 once and release it immediately.

INSERTING AND FASTENING DRILL BITS

Through turning the collar of the chuck 1 clockwise or counter-clockwise the jaws are

positioned so the drill bit shank can be inserted inside the choke. By turning the collar of

chuck 1 clockwise the jaws tighten the drill bit shank. Fix the drill bit finally in the chuck by

means of the special chuck key, tightening equally in all three bores.

TWO-SPEED SELECTOR SWITCH

Rotate switch 9 to 180° clockwise or counterclockwise, in order to select one or the other

speed range.

SELECTION OF RPM VALUE

The necessary speed can be pre-selected by rotating the regulator dial 4.

REVERSING

The extreme position of lever 2 to the right is equivalent to clockwise rotation, the extreme

position to the left - to counter-clockwise rotation.

OPERATION MODE SELECTION

•

Drilling in metal, wood, etc. The switch 8 is in its extreme right position the symbol “drill

bit” being exposed.

•

Drilling in concrete, stone, etc. The ON/OFF switch 8 is in its extreme left position and

the symbol “hammer” is exposed.

OPERATION
