ENGLISH

(Original instructions)

5

Using an extension cable

♦

Always use an approved extension cable suitable for

the power input of this tool (see technical data). Before

use, inspect the extension cable for signs of damage,

wear and ageing. Replace the extension cable if

damaged or defective. When using a cable reel, always

unwind the cable completely. Use of an extension cable

not suitable for the power input of the tool or which is

damaged or defective may result in a risk of fire and

electric shock.

Features

This tool includes some or all of the following features.

1. Variable speed switch

2. Lock-on button

3. Forward/reverse button

4. Drilling mode selector

5. Chuck

6. Depth stop

7. Side handle

Assembly.

Warning!

 Before assembly, make sure that the

tool is switched off and unplugged.

Fitting the side handle and depth stop (fig.A,B)

♦

Turn the grip counter clockwise until you can slide

the side handle (7) onto the front of the tool as shown

(fig.A).

♦

Rotate the side handle into the desired position.

♦

Insert the depth stop(6) into the mounting hole as

shown (fig.B).

♦

Set the drilling depth as described below.

♦

Tighten the side handle by turning the grip clockwise.

Fitting a drill bit (fig.C)

♦

Open the chuck by turning the sleeve (5) counter

clockwise.

♦

Insert the bit shaft (9) into the chuck (drill bit not

included).

♦

Insert the chuck key(10) into each hole (8) in the side of

the chuck and turn clockwise until it is tight.

Removing and refitting the chuck (fig.D)

♦

Open the chuck as far as possible.

♦

Remove the chuck retaining screw, located in the

chuck, by turning it clockwise using a screwdriver.

♦

Tighten an Allen key into the chuck and strike it with a

Impact as shown.

♦

Remove the Allen key. Remove the chuck by turning it

counter clockwise.

♦

To refit the chuck, screw it onto the spindle and secure

it with the chuck retaining screw.

Use

Warning!

 Let the tool work at its own pace.Do not

overload.

Warning!

 Before drilling into walls, floors or

ceilings, check for the location of wiring and pipes.

Selecting the direction of rotation (fig.E)

For drilling and for tightening screws, use forward

(clockwise) rotation For loosening screws or removing a

jammed drill bit, use reverse (counter clockwise) rotation.

♦

To select forward rotation, push the forward/reverse

button (3) to the left position.

♦

To select reverse rotation, push the forward/reverse

button (3) to the right. Warning! Never change the

direction of rotation while the motor is running.

Selecting the drilling mode

♦

For drilling in masonry, set the drilling mode selector (4)

to the  position.

♦

For drilling in other materials and for screwdriving, set

the drilling mode selector to the  position.

Setting the drilling depth (fig.B)

♦

Slacken the side handle (7) by turning the grip counter

clockwise.

♦

Set the depth stop(6) to the desired position. The

maximum drilling depth is equal to the distance

between the tip of the drill bit and the front end of the

depth stop.

♦

Tighten the side handle by turning the grip clockwise.

Switching on and off

♦

To switch the tool on, press the variable speed

switch(1). The tool speed depends on how far you press

the switch. As a general rule, use low speeds for large

diameter drill bits and high speeds for smaller diameter

drill bits.

♦

For continuous operation, press the lock-on button (2)

and release the variable speed switch. This option is

available only at full speed in both forward and reverse

modes.

♦

To switch the tllo off, release the variable speed switch.

To switch the tool off when in continuous operation,

press the variable speed switch again and release it.

♦

Based on the different applications, turn around the

speed dial(11) to control the maximum speed.

Drilling in metal

Start drilling with slow speed and increase to full power

while applying firm pressure on the tool. A smooth even

flow of metal chips indicates the proper drilling rate. Use a

cutting lubricant when drilling metals. The exceptions are

cast iron and brass which should be drilled dry.
