7

Original instructions

EN

WARNING:

 When changing the gear ensure

the power tool is switched off.

  1. To select the low gear (low speed, high torque

setting), push the gear selector (3) forward, towards
the chuck. The digit 1 on the switch will be displayed.

  2.  To select the high gear (high speed, low torque

setting), push the gear selector (3) back, away from
the chuck. The digit 2 on the switch will be displayed.

INSERTING AND REMOVING THE OPERATING
TOOL (Fig. 6)

WARNING:

 Remove the battery or set the for-

ward/reverse switch (6) in central (neutral) position (A).

The  drill  is  fitted  with  auto  spindle  lock  which  means  if

you try to rotate the chuck by hand the spindle will au-
tomatically lock. This means you only need to grasp the

chuck and rotate the chuck housing to remove or fit the

operating tool.

▪

Hold the machine with one hand and rotate the chuck

with the other hand.

- To open the chuck, rotate it anti-clockwise. (B)

- To close the chuck, rotate it clockwise. (D)

▪

Insert the operating tool. (C)

▪

Close the chuck.

▪

Perform a test run to check that the operating tool is

properly clamped in the centre.

FITTING AND REMOVING THE AUXILIARY
HANDLE (BUR2 18LI HD)

WARNING:

 Remove the battery or set the for-

ward/reverse switch (6) in central (neutral) position (A).

▪

To mount the auxiliary handle (12) refer to

Fig.7a.

(A, B, C, D).

▪

To remove the auxiliary handle (12) refer to

Fig.7b.

(A, B, C).

▪

To change the auxiliary handle position refer to

Fig.8.

(A, B, C, D).

Ensure  that  the  auxiliary  handle  (12)  is  firmly  tightened

prior to starting operation.

DRILLING

Drilling metal

▪ For maximum performance, use high speed steel bits

for metal or steel drilling.

▪

Ensure that the torque adjustment collar (2) is at posi-

tion “drill bit”.

▪

Begin drilling at a very low speed to prevent the bit

from slipping off the starting point.

▪

Always clamp sheet metal.

▪

Support thin metal with a block of wood to avoid dis-

torting it.

▪

Use a punch to mark the centre of the hole.

▪

Use a suitable lubricant for the material you are work-

ing on.

Material

Lubricant

Steel

Oil

Aluminium

Turpentine or paraffin

Brass, copper or
cast iron

Do not lubricate

Drilling plastics and plastic coated chipboard

▪

Use high speed drill bits.

▪

Refer to “Drilling wood” below.

Drilling masonry (BUR2 18Li HD)

▪ For  maximum  performance  use  carbide-tipped  ma

-

sonry impact bits when drilling holes in brick, tile,
concrete etc.

▪

Turn the speed selector (3) to position “2”, then rotate

the torque collar (2) to the impact drill position.

▪

Apply light pressure and medium speed for best re-

sults in brick.

▪

Apply additional pressure and high speed for hard ma-

terials such as concrete.

▪

When drilling holes in tile, practice on a scrap piece to

determine the best speed and pressure.

Drilling wood

▪ For maximum performance, use high speed steel bits

for wood drilling.

▪

Ensure that the torque adjustment collar (2) is at posi-

tion “drill bit”.

▪

Begin drilling at a very low speed to prevent the bit

from slipping off the starting point. Increase the speed
as the drill bites into the material.

▪

When drilling through holes, place a block of wood

behind the work piece to prevent ragged or splintered
edges on the back side of the hole.

All drilling operations

▪

Use only sharp drill bits.

▪

Mark off the centre of the hole using a centre punch

or nail.

SCREWING / UNSCREWING

Select the appropriate torque by placing one of the num-
bers, marked on the torque adjustment collar (2), against
the arrow on the tool body.
Insert the necessary bit.

WARNING:

 Over-tightening can result in the

screw breaking or damage to the end of the driver bit.

WARNING:

  If the machine is held at an angle

to the screw being tightened, the head of the screw

may be damaged, or the specified torque may not be

transmitted to the screw. Always keep the machine
and the screw being tightened in a straight line.
