OPERATION

NOTE:

The drill will not run unless the rotation selector is

pushed fully to the left or right.

Avoid running the drill at low speeds for extended periods

of  time.  Running  at  low  speeds  under  constant  usage

may cause the dr ill to become o verheated. If this occurs ,

cool the drill by running it without a load and at full speed.

INTERNAL SPINDLE LOCK

The inter nal spindle loc k allo ws the user single-handed

control of chuck adjustments and bit changes . Squeezing

the chuc k body stops the chuc k ja ws from tur ning. F or

bit changes and chuc k adjustments , squeez e the chuc k

body and turn.

KEYLESS CHUCK

The dr ill has a k eyless chuc k to tighten or release dr ill

bits in the chuc k ja ws. The arro ws on the chuc k indicate

which direction to rotate the chuck body in order to

LOCK

(tighten) or

UNLOCK

 (release) the drill bit.

WARNING

Do not hold the chuck with one hand and use the

power of the dr ill to tighten the chuc k jaws on the

drill bit. The chuc k body could slip in y our hand,

or your hand could slip and come in contact with

the rotating dr ill bit. This could cause an accident

resulting in serious personal injury.

TWO-SPEED GEAR TRAIN (HI-LO)

The dr ill has a tw o-speed gear tr ain designed f or dr illing

or dr iving at

LO (1)

 or

HI (2

) speeds . A slide s witch is

located on top of the dr ill to select either

 LO (1)

 or

HI (2)

speed. When using drill in the

LO (1)

 speed range, speed

will decrease and unit will ha ve more po wer and torque .

When using dr ill in the

HI (2)

 speed r ange, speed will

increase and unit will ha ve less po wer and torque . Use

LO (1)

 speed f or high po wer and torque applications and

HI (2)

 speed for fast drilling or driving applications.

NOTE:

  If y ou ha ve difficulty changing from one gear

range to the other, turn the chuck by hand until the gears

engage.

See Figure 6.

CAUTION:

Never change gears while the tool is r unning.

Failure to obey this caution could result in serious

damage to the drill.

QUICK MODE SELECTOR

The Quic k Mode Selector allo ws y ou to quic kly s witch

from drill mode to drive mode.

In gener al, dr ill mode should be used f or dr illing and

other hea vy duty applications . Dr ive mode should be

used for driving screws

 mode should be used

for impact drilling.

SELECTING DRIVE OR DRILL SETTING

See Figure

Using the char t belo w, choose correct speed and mode

the type of bit, fastener, and material you will be using.

■

Choose your

 APPLICATION

■

Choose the correct

 SPEED: (1/LOW or 2/HIGH)

■

Choose  the  correct

 MODE: (DRIVE, DRILL, OR

HAMMER)

. Hammer

 5-6.

1. APPLICATION

2. SPEED

3. MODE

• Lag screws up to 9.5 mm dia. by 38.1 mm long

• Hole saw up to 50.8 mm

• Spade bits up to 38.1 mm

• Drill bits up to 12.7 mm

• Drilling into metal

• Concrete screws

1/LOW

DRILL MODE

(TORQUE ADJUSMENT NOT ACTIVE)

2/HIGH

• Drill bits up to 6.4 mm

• Deck or wood screws up to

76

.

2

 mm long

• Self tapping screws

1/LOW

DRIVE MODE

• Deck or wood screws up to

76

.

2

 mm long

• Small screws or delicate work that requires more control

2/HIGH

• Masonry bit up to 12.7 mm

1/LOW

HAMMER MODE

(TORQUE ADJUSMENT NOT ACTIVE)

2/HIGH

See Figure 4.

See Figure 5.
