ENGLISH

en

14

Instructions on charging the battery pack can be

found in the operating instructions of the Metabo

charger.

7.3 Removing and inserting the battery pack

Fig. C

7.4 Setting the direction of rotation,

engaging the transporting safety device

(switch-on lock)

Fig. D

7.5 Select the gear

Fig. E

Do not set the gear switch (4) unless the motor

has stopped completely!

7.6 Set drill, hammer drill

Fig. A

Activate slide switch (3).

7.7 Setting torque control, maximum torque,

pulse function

Do not work for long periods with pulse

function switched on! (The motor can

overheat.)

Fig. F

Set the desired operating mode at the setting wheel

(13):
1...10 =  Torque

control

= maximum

torque

= Pulse

function

7.8 Switching On/Off, setting the speed

Fig. A

Switching on, speed:

 press the trigger switch (15).

Press in the trigger switch to increase the

rotational speed.

Switching off:

 release the trigger switch (15). Note:

the noise that the machine makes when it

switches off is due to the design (quick stop)

and has no influence on the function or the

service life of the machine.

7.9 Keyless chuck

Fig. G

With a soft tool shank, retightening may be required

after a short drilling period.

Instructions for machines with the designation

SB...:

1. The grating sound which may be heard after

opening the chuck is functional and is stopped

by turning the sleeve in the opposite direction.

2. Clamping the tool:

Turn sleeve in direction "GRIP, ZU" until the

noticeable mechanical resistance has been

overcome.

Caution! The tool is not yet clamped!

 Keep

turning the sleeve (

it must "click" when

turning

), until it cannot be turned any further -

only now

 is the tool

 securely

 clamped.

Cleaning:

 from time to time, hold the machine

vertically with the chuck facing downwards and

turn the sleeve fully in the direction "GRIP, ZU"

and then turn fully in the direction

"AUF, RELEASE". The dust collected falls from

the keyless chuck.

7.10 Unscrewing the drill chuck (only for

machines without quick change system

Quick)

The user cannot unscrew and screw on the chuck.

Contact the customer service.

7.11 Chuck with quick-change system Quick

(for machines with the designation ...BL

Q...)

Fig. H.

To remove:

Push the interlock ring forward (a),

advance and pull off the chuck (b).

To fit:

 push the interlock ring forward and move the

chuck as far as the limit stop on the drill spindle.

7.12 Fitting the belt hook (equipment-

specific) / bit depot (equipment-specific)

Fig. I

Fit the belt hook (8) as shown.

Fit the bit depot (7) as shown.

8.1 Defective electronic safety shutdown

(...LTX BL...)

Red continuous lighting of the LED lamp (14)

signals a defective safety shutdown.Have the

machine repaired. See chapter 10.

8.2 The machine's multifunctional

monitoring system

If the machine switches off automatically, the

machine electronics have activated automatic

protection mode. There will be a warning signal

(beep). The beeping stops after a maximum of 30

seconds or when the trigger switch (15) is released.

In spite of this protective function, overloading

is still possible with certain applications and

can result in damage to the machine.

Causes and remedies:

1.

Battery pack almost empty

Fig. A, B

(The

electronics protect the battery pack against

damage through total discharge).

If one LED (11) is flashing, the battery pack is

almost flat. If necessary, press the button (10)

and check the LED lamps (11) to see the charge

level. If the battery pack is almost flat, it must be

recharged.

2. Long continuous overloading of the machine will

activate the

temperature cut-out

.

Leave the machine or battery pack to cool.
Note: if the battery pack feels very warm, the

pack will cool more quickly in an "AIR COOLED"

charger.
Note: the machine will cool more quickly if you

operate it at idling speed.

3. Metabo

safety shutdown

: the machine has

SHUT DOWN by itself. If the speed suddenly

drops (for example, if the machine suddenly

8. Troubleshooting
