ENGLISH

en

10

Pull the plug out of the socket before making any
adjustments, changing tools, carrying out
maintenance or cleaning.

4.2

Special safety instructions for cordless

machines:

Avoid inadvertent starts by making sure that the
machine is switched off before fitting the battery
pack.
Remove the battery pack from the machine before
making any adjustments, changing tools,
maintaining or cleaning.

Protect battery packs from water and
moisture!

Do not expose battery packs to fire!

Do not use faulty or deformed battery packs!
Do not open battery packs!
Do not touch contacts or short-circuit battery packs!

A slightly acidic, flammable fluid may leak
from defective Li-ion battery packs!

If battery fluid leaks out and comes into
contact with your skin, rinse immediately
with plenty of water. If battery fluid leaks out

and comes into contact with your eyes, wash them
with clean water and seek medical attention
immediately!
LED lights (9): Do not observe the LED radiation
directly with optical instruments.

See page 2.

1 Futuro Top * keyless chuck
2 Side handle/Additional handle with vibration

damping

3 Thumb-wheel for gear selection *
4 Rotation selector switch
5 Speed preselection wheel *
6 Trigger  switch
7 Locking button for continuous activation
8 Handle
9 LED  lights  *

10 Battery pack release button *

11 Belt hook *

12 Battery pack *

13 Capacity and signal indicator *
14 Capacity indicator button *

* depending on the model / features

6.1

Assembly of the side handle (2)

For safety reasons, always use the additional
handle supplied.

- Open the clamping ring by turning the side handle

(2) counter-clockwise.

- Push the additional handle onto the collar of the

machine.

- Only for BE 600/13-2: Advance the side handle

until it can be twisted. Then pull it back into
position at the required angle.

- Tighten the side handle pulling firmly.

6.2

For mains powered machines only

Before plugging in, check that the rated mains
voltage and mains frequency, as stated on the

type plate match your power supply.

Always install an RCD with a maximum trip
current of 30 mA upstream.

6.3

For cordless machines only

Battery pack

Charge the battery pack (12) before use.
If performance diminishes, recharge the battery
pack.
The ideal storage temperature is between 10°C and
30°C.
Li-Ion battery packs "Li-Power" have a capacity and
signal indicator (13):
- Press the button (14), the LEDs indicate the

charge level.

- If one LED is flashing, the battery pack is almost

flat and must be recharged.

Removing and inserting the battery pack

Removal: Press the battery pack release button
(10) and pull the battery pack (12) forwards.
To insert: Slide the battery pack (12) in until it
engages.

Installation of belt hook

Attach the belt hook (11) as shown.

7.1

Setting the direction of rotation,

engaging the transporting safety device

(switch-on lock)

Only activate the rotation selector switch (4)
when the motor has completely stopped.

See page 2:

R

= Clockwise setting

L

= Counter-clockwise setting

0

= Central position: transportation lock setting

(switch-on lock)

7.2

Select the gear (depending on features)

Select the required gear by rotating the thumb
wheel (3).
Change speed only when the machine is in the
process of running down
(briefly switch On and Off).

1. st gear (low speed, high torque) e.g. for
screwdriving, drilling

2. nd gear (high speed) e.g. for drilling

5. Overview

6. Commissioning

7. Use
