9 ENGLISH

Installing driver bit holder

Optional accessory

►

Fig.11:

1.

 Driver bit holder

2.

 Driver bit

Fit the driver bit holder into the protrusion at the tool foot

on either right or left side and secure it with a screw.

When not using the driver bit, keep it in the driver bit

holders. Driver bits 45 mm-long can be kept there.

Installing side grip (auxiliary handle)

Optional accessory

►

Fig.12:

1.

 Protrusion

2.

 Arm

3.

 Recess

4.

 Grip

Insert the side grip so that the protrusions on the arm

fit in the recesses on the tool. Then tighten the grip by

turning clockwise.

Depending the operations, you can install the side grip

either right or left side of the tool.

OPERATION

CAUTION:

Always insert the battery cartridge

all the way until it locks in place.

 If you can see the

red indicator on the upper side of the button, it is not

locked completely. Insert it fully until the red indicator

cannot be seen. If not, it may accidentally fall out of

the tool, causing injury to you or someone around

you.

CAUTION:

When the speed comes down

extremely, reduce the load or stop the tool to

avoid the tool damage.

Hold the tool firmly with one hand on the grip and the

other hand on the bottom of the battery cartridge to

control the twisting action.

Screwdriving operation

CAUTION:

Adjust the adjusting ring to the

proper torque level for your work.

CAUTION:

Make sure that the driver bit is

inserted straight in the screw head, or the screw

and/or driver bit may be damaged.

First, turn the action mode changing ring so that the

arrow on the tool body points to the

 marking.

Place the point of the driver bit in the screw head and

apply pressure to the tool. Start the tool slowly and then

increase the speed gradually. Release the switch trigger

as soon as the clutch cuts in.

►

Fig.13

NOTE:

 When driving wood screw, pre-drill a pilot hole

2/3 the diameter of the screw. It makes driving easier

and prevents splitting of the workpiece.

Hammer drilling operation

CAUTION:

There is a tremendous and sud-

den twisting force exerted on the tool/drill bit

at the time of hole breakthrough, when the hole

becomes clogged with chips and particles, or

when striking reinforcing rods embedded in the

concrete.

First, turn the action mode changing ring so that the

arrow on the tool body points to the

 marking. The

adjusting ring can be aligned in any torque levels for

this operation.

Be sure to use a tungsten-carbide tipped drill bit.

Position the drill bit at the desired location for the hole,

then pull the switch trigger. Do not force the tool. Light

pressure gives best results. Keep the tool in position

and prevent it from slipping away from the hole.

Do not apply more pressure when the hole becomes

clogged with chips or particles. Instead, run the tool at

an idle, then remove the drill bit partially from the hole.

By repeating this several times, the hole will be cleaned

out and normal drilling may be resumed.

Blow-out bulb

Optional accessory

►

Fig.14:

1.

 Blow-out bulb

After drilling the hole, use the blow-out bulb to clean the

dust out of the hole.

Drilling operation

First, turn the action mode changing ring so that the

arrow points to the

 marking. Then proceed as

follows.

Drilling in wood

When drilling in wood, the best results are obtained

with wood drills equipped with a guide screw. The guide

screw makes drilling easier by pulling the drill bit into

the workpiece.

Drilling in metal

To prevent the drill bit from slipping when starting a

hole, make an indentation with a center-punch and

hammer at the point to be drilled. Place the point of the

drill bit in the indentation and start drilling.

Use a cutting lubricant when drilling metals. The excep-

tions are iron and brass which should be drilled dry.
