English

11

5. How to select tightening torque and rotational speed

Table 5

Use

Clutch Dial

Rotating speed selection (Position of the shift knob)

Position

LOW (Low speed)

HIGH (High speed)

Machine screw

1 – 22

For 6 mm or smaller diameter
screws.

Driving

Wood screw

1 –

For 6 mm or smaller nominal
diameter screws. (DS18DCL)

For 6 mm or smaller nominal
diameter screws. (DS14DCL)

Wood

For 38 mm or smaller
diameters. (DS18DCL)

Drilling

For 30 mm or smaller
diameters. (DS14DCL)

Metal

For drilling with a metal working drill bit.

For 6 mm or smaller
diameter screws.

For 4.8 mm or smaller
nominal diameter screws.
(DS18DCL)

For 3.8 mm or smaller
nominal diameter screws.
(DS14DCL)

For 24 mm or smaller
diameters. (DS18DCL)

For 12 mm or smaller
diameters. (DS14DCL)

Work

Suggestions

Drilling

Wood

Use for drilling purpose.

Steel

Machine screw

Use the bit or socket matching the screw diameter.

Driving

Wood screw

Use after drilling a pilot hole.

Table 4

2. Tightening torque adjustment

(1) Tightening torque

Tightening torque should correspond in its intensity
to the screw diameter. When too strong torque is
used, the screw head may be broken or be injured.
Be sure to adjust the clutch dial position according
to the screw diameter.

(2) Tightening torque indication

The tightening torque differs depending on the type
of screw and the material being tightened.
The unit indicates the tightening torque with the
numbers “1, 3, 5 ... 22” on the clutch dial, and a
dots. The tightening toque at position “1” is the
weakest and the torque is strongest at the highest
number (See

Fig. 4

).

(3) Adjusting the tightening torque

Rotate the clutch dial and line up the numbers “1,
3, 5 ... 22” on the clutch dial, or the dots, with the
triangle mark on the outer body. Adjust the clutch
dial in the weak or the strong torque direction
according to the torque you need.

CAUTION

䡬

The motor rotation may be locked to cease while
the unit is used as drill. While operating the driver
drill, take care not to lock the motor.

䡬

Too long hammering may cause the screw broken
due to excessive tightening.

3. Change rotation speed

Operate the shift knob to change the rotational
speed. Move the shift knob in the direction of the
arrow (See

Figs. 6

  and

7

).

When the shift knob is set to “LOW”, the drill
rotates at a low speed. When set to “HIGH”, the
drill rotates at a high speed.

CAUTION

䡬

When changing the rotational speed with the shift
knob, confirm that the switch is off.
Changing the speed while the motor is rotating will
damage the gears.

䡬

When setting the shift knob to “HIGH” (high speed)
and the position of the clutch dial is “17” or “22”,
it may happen that the clutch does not engaged
and that the motor is locked. In such a case, please
set the shift knob to “LOW” (low speed).

䡬

If the motor is locked, immediately turn the power
off. If the motor is locked for a while, the motor
or battery may be burnt.

䡬

To extend the lifetime, the lithium-ion battery equips
with the protection function to stop the output.
Therefore, if the tool is overloaded, the motor may
stop. However, this is not the trouble but the result
of protection function. In this case, release the switch
of tool and eliminate the causes of overloading.

4. The scope and suggestions for uses

The usable scope for various types of work based
on the mechanical structure of this unit is shown
in

Table 4

.
