15
TECHNICAL PARAMETERS
R AT E D PA R A M E T E R S
Cordless drill 58G019
Parameter
Value
Battery voltage
18 V DC
Range of idle rotational speed
gear I
0-500 min
-1
gear II
0-1700 min
-1
Range of quick release chuck
2 -13 mm
Torque control range
1 – 16 +
drilling
Max. torque (soft drive)
38 Nm
Max. torque (hard drive)
58 Nm
Protection class
III
Weight
1,2 kg
Year of production
2018
58G019 defines type and indication of the device
Graphite Energy+ System Battery
Parameter
Value
Battery
58G001
58G004
Battery voltage
18 V DC
18 V DC
Battery type
Li-Ion
Li-Ion
Battery capacity
2000 mAh
4000 mAh
Ambient temperature range
4
0
C – 40
0
C
4
0
C – 40
0
C
Charging time for charger 58G002
1 h
2 h
Weight
0,400 kg
0,650 kg
Year of production
2018
2018
Graphite Energy+ System Charger
Parameter
Value
Charger type
58G002
Supply voltage
230 V AC
Power supply frequency
50 Hz
Charging voltage
22 V DC
Max. charging current
2300 mA
Ambient temperature range
4
0
C – 40
0
C
Charging time of the battery 58G001
1 h
Charging time of the battery 58G004
2 h
Protection class
II
Weight
0,300 kg
Year of production
2018
N O I S E L E V E L A N D V I B R AT I O N PA R A M E T E R S
Sound pressure level
Lp
A
= 77,5 dB(A) K= 3 dB(A)
Sound power level
Lw
A
= 88,5 dB(A) K= 3 dB(A)
Vibration acceleration
a
h
= 2,04 m/s
2
K= 1,5 m/s
2
Noise and vibration information
Noise produced by the device is defined with: level of produced
sound pressure Lp
A
and level of sound power Lw
A
(where K is
measurement uncer tainty). Vibrations produced by the device
are defined with vibration acceleration value a
h
(where K is
measurement uncer tainty).
Sound pressure Lp
A
, sound power Lw
A
and vibration acceleration
ah specified in this manual have been measured in accordance
with EN 60745-1. Specified vibration level a
h
can be used
to compare tools and for initial evaluation of exposition to
vibrations.
Specified vibration level is representative for main applications
of the device. When the device is used for other purposes or
with different working tools, the vibration level may change.
Insufficient or too rare maintenance may increase vibration
level. The abovementioned factors may lead to higher exposure
to vibrations during whole working time.
To precisely define exposure to vibrations, include periods
when the device is switched off and when it is switched on
but not used for working. Once all factors have been carefully
considered, total exposition to vibrations may be significantly
lower.
To protect the user from results of exposure to vibrations, use
additional safety measures such as: device and working tool
periodic maintenance, proper hand temperature conditions,
good work organisation.
ENVIRONMENTAL PROTECTION
Electrical equipment must not be disposed off
with household waste and, instead, should be
utilized at appropriate facilities. Information
on utilization can be provided by the product
vendor or the local authorities. Waste electrical
and electronic equipment contains substances
that are not neutral to the natural environment.
Equipment that is not recycled constitutes a
potential hazard to the environment and to
human health.
Li-Ion
Storage batteries/batteries must not be disposed
with domestic waste, put in a fire or into the
water. Damaged or used up storage batteries
must be properly recycled in compliance with the
current directive pertaining to disposal of storage
batteries and batteries.
* Right to introduce changes is reser ved.
