PDC 18/4 Li
11
GB
The specified emission values (vibration, noise)
– are used to compare machines.
– They are also used for making preliminary esti-
mates regarding vibration and noise loads during
operation.
– They represent the primary applications of the
power tool.
Increase possible for other applications, with other
insertion tools or if not maintained adequately. Take
note of idling and downtimes of machine!
3
Intended use
Cordless impact drills are suitable for
– drilling in metal, wood, plastic and similar mate-
rials,
– impact drilling into walls, concrete and similar
building materials,
– inserting and tightening screws
The user is liable for improper or non-in-
tended use; this also includes continuous in-
dustrial operation.
4
Technical data
* Speed specifications with fully charged battery
pack.
** The maximum speed is reduced in the lower
torque stages (values in counterclockwise rotation).
5
Machine features
Accessories shown or described are sometimes not
included in the scope of delivery.
The specified illustrations appear at the beginning
of the Operating Instructions.
6
Commissioning
6.1
Changing the battery pack
Inserting the battery pack [2 A]
Removing the battery pack[2 B]
L
Battery pack is ready for use immediately upon
delivery and can be charged at any time.
6.2
Light and battery capacity indicator
The LED on the lamp
[1-2]
is both a light and
a battery capacity indicator
.
X
Press the LED light switch
[1-1]
:
1x ... LED, working area illumination
2x ... capacity indicator, indicates the charging
state of the battery pack (not with NiCd and
NiMH battery packs)
Drilling in metal
a
h
= 5,6 m/s
2
K = 1,5 m/s
2
Fastening
a
h
< 2,5 m/s
2
K = 1,5 m/s
2
Impact drilling into con-
crete
a
h
= 12,4 m/s
2
K = 3,0 m/s
2
Cordless percussion drill
PDC 18/4 Li
Motor voltage
18 V
Idling speed*
1st gear
0 - 400 min-1
2nd gear
0 - 850 min
-1
3rd gear 0 - 1850 min
-1
4th gear 0 - 3800 min
-1
Torque for easy/tough fastening
applications
40/60 Nm
Adjustable torque**
1st gear
1,2 - 11,5 Nm
2nd gear
0,8 - 7,2 Nm
3rd gear
0,6 - 4,7 Nm
4th gear
0,6 - 2,6 Nm
Chuck clamping range
1,5 - 13 mm
Drill diameter max.
Wood
50 mm
Metal
13 mm
Fastening in pine
max.
10 mm
Tool holder in drill spindle
1/4"
Weight without battery pack with
Centrotec
1,3 kg
[1-1]
LED light switch
[1-2]
LED lamp
[1-3]
Bit store
[1-4]
On/Off switch
[1-5]
Clamping sleeve
[1-6]
Drilling/impact drilling selector switch
[1-7]
Gear switch
[1-8]
Torque thumbwheel
[1-9]
Right/left switch
[1-10]
Belt clip
[1-11]
Button for releasing the battery pack
[1-12]
Insulated gripping surfaces (grey shaded
area)
LED green – lit continuously:
charged > 60 %
Cordless percussion drill
PDC 18/4 Li
