12

6

Starting up and using the machine

 WARNING

Risk of accident if the machine is operated us-
ing unauthorised voltages or frequencies.

-

The mains voltage and the frequency of the

power source must correspond with the spec-

ifi cations on the machine’s name plate.

-

In North America, only Festool machines with

the voltage specifi cations 120 V/60 Hz may be

used.

 WARNING

Risk of accident, electric shock



Always pull the plug out of the socket before

performing any type of work on the machine.

CAUTION

Inhaling the dust may damage the respiratory
tract.



When working with dust, you must wear res-

piratory protection.

6.1

Tightening the stirrer
(see Fig. [2])



Screw in the stirrer

[2-3]

 with endpiece M14x2

(wrench size 22) by turning it to the right in the

adapter  ErgoFix

[2-1]

 (wrench size 19) and

use the wrench to tighten it.



Fasten the  ErgoFix  adapter to the stirrer bar,

then insert the assembled stirrer into the slot

of the spindle.

To set-up the working height see chapter 6.5.

6.2

Switching the machine on and off

  Always hold the machine with both hands.

Pressing the switch

[1-10]

 puts the machine into

operation and taking your hand away from the

switch stops the machine from working.

Using the switch button to control the speed (ac-
celeration function switch)

You can use the switch

[1-10]

 to change the level

of the speed until it reaches the speed range that

is set by the speed controller.

Continuous operation

By pressing the switch

[1-10]

 as far as it goes and

pressing the locking switch button

[1-2]

 at the

same time, you can activate continuous operation.

Press and release the switch button

[1-10]

 again

to switch off continuous operation.

6.3 Control

electronics

Limiting the starting current

The electronically-controlled soft start ensures

that the machine starts up smoothly.
At the same time, this also prevents the materi-

als to be stirred from spurting out of the mixing

container. Thanks to the low starting current of

the machine, a 10 A fuse is suffi cient.

Electronic speed preselection

You can use the speed controller

[1-4]

 to set the

speed:

* MX 1200/2 E EF / ** MX 1600/2 E EF

1st speed

*

**

2nd speed

*

**

Level 1

150 150 Level 1

320 320

Level 2

200 200 Level 2

440 440

Level 3

220 240 Level 3

470 520

Level 4

290 265 Level 4

570 570

Level 5

330 280 Level 5

680 600

Level 6

360 300 Level 6

780 650

The speed depends on the stirrer rod that is used

and on the material that you want to process.

Overload protection

An electronic overload protection protects the mo-

tor from damage if there is an extreme overload.
In this case, the motor remains at a standstill and

only starts up again once the load has been re-

moved. To restart the machine, you must switch

it on again.

Constant Electronic function

The Constant Electronic function maintains an

almost constant speed and load; this ensures that

the material is stirred evenly.

Temperature-dependent overload protection

To protect the machine against overheating if you

are using it for an extremely prolonged period,

switch the safety electronics to the cooling mode

as soon as the critical temperature is reached.

You cannot load the machine and it runs at a re-

duced speed. Approx. 2 minutes after cooling, the

machine is again ready for use and fully able to

take loads.

6.4

Speed selector switch

Two rpm ranges can be preselected with the

speed selector switch

[1-6]

:
