16

take loads.

Protection against re-starting

Prevents the uncontrolled starting of the de-

vice after current supply cut off. For re-starting,

the device must be fi rst switched off and again

switched on.

6.4

Speed selection switch

(VALID for the type MX 1000/2 E EF)

You can use the speed selection switch

[1-9]

 to

preselect two speed ranges:

1st speed

2nd speed

360 – 630  rpm

580 – 1010  rpm

The gears can be switched when the machine is

running down, however not under full load.

6.5

ErgoFix

 interface

Height setting

The working height of the machine can be indi-

vidually adjusted to achieve an upright working

position.



Push the casing of the ErgoFix adapter

[1-7]

 in

the direction of the machine to move it as far

as it goes

[1-7]

 and hold it tight.



By pulling on the stirrer rod, you can pull the

 ErgoFix  adaptor

[1-8]

 out of the machine spin-

dle. In this way, you can adjust fi ve  different

working heights. One step is 2 cm. The maxi-

mum adjustment movement is 8 cm.



Then release the clamping ring of the ErgoFix

adapter

[1-7]

 and check that the adapter

[1-8]

is seated securely in the machine spindle.

Quick change function

NOTE



Ensure that the adapter

[1-8]

 remains clean.



Do not lubricate the adaptor

[1-8]

.



Only press the ErgoFix casing

[1-7]

 when the

machine is not in operation.

The ErgoFix interface enables you to easily and

quickly remove the stirrer rod from the machine.



Push the clamping ring of the ErgoFix adapter

[1-7]

 in the direction of the machine to move it

as far as it goes and hold it tight.



By pulling on the stirrer rod, you can pull the

ErgoFix adaptor

[1-8]

 completely out of the

machine spindle.

Changing the stirrer



Adapter ErgoFix

[2-1]

 after worn-out of stirrer

rod can be reused.



Set the wrench

[2-2]

 on the hexagon of the stir-

rer endpiece

[2-3]

 and turn to the left to screw

the stirrer rod out of the ErgoFix adapter

[2-1]

.

6.6 Stirrer

To mix different material mixtures together, use

different Festool stirrers: see the catalogue

PJ Uni

For wall paints,

emulsion paints,

ready-made fi ller,

ready-mix plaster,

varnishes/glazes

RS

For wall paints,

emulsion paints,

pastes, varnishes

casting compounds,

bitumen, sludges

HS2

For tile adhesives,

joint sealant, adhesive

mortar, ready-mix

plaster, screed, fi llers,

levelling compounds

HS3R

For mortar, concrete,

cement and lime

plaster adhesive fi ller,

screed, quartz-fi lled

epoxy resin, thick

bitumen coating

HS3L

For gypsum plaster,

emulsion paints,

varnishes wall paints,

casting compounds

WS

For paints, varnishes,

wall paints, emul-

sion paints, plasters,

glues, tile adhesives
