8

EN

Description

The numbers in the text refer to the diagrams on
pages 2 - 3.

Fig. A

1. Machine
2. Battery
3.  Battery unlock button
4.  Work light
5. Charger
6.  Charger LED indicator
7. Chuck
8.  Gear selection switch
9.  Direction switch
10.  On / off switch
11.  Torque adjustment ring
12.  Belt hook

3. OPERATING

 The battery must be charged before first
use.

Removing the battery from the machine (Fig. B)

•   Push the battery unlock buttons (3) and pull

the battery out of the machine.

Inserting the battery into the machine (Fig. B)

 Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.

•   Insert the battery (2) into the base of the

machine.

•   Push the battery further forward until it clicks

into place.

Charging the battery (with the charger) (Fig. C)

•   Plug the charger plug into an electrical outlet

and wait for a while. The LED indicator on
the battery (6) will lighten up and show the
charging status.

•   Plug the output of the charger into the round

socket of the battery.

LED indicator (6) (Fig. C)

The battery has 1 LED indicator (6) which
indicates the status of the charging process:

LED

Charger status

Red

Battery charging in progress

Green

Battery charging finished, battery fully charged

•   After the battery is fully charged remove the

charger plug from the outlet and remove the
battery from the charger.

 When the machine is not being used
over a longer period of time it is best to
store the battery in charged condition.

Fitting and removing drills or screwdriver bits
(Fig. D)

 Always remove the battery before
mounting an accessory.

The drill chuck (7) is suitable for drills and screw-
driver bits with round shaft as well as hexagonal
shaft.
•   Hold the machine firmly with one hand
•   Open the drill chuck (7) by rotating the chuck

with your other hand in clockwise direction until
it is opened far enough for the bit to slide in.

•   Insert the shaft of the drill or screwdriver bit
•   Tighten the drill chuck again by firmly rotating

the chuck (7) counterclockwise.

•   Check if the bit is centered well by shortly

activating the machine´s on/off switch.

Adjusting the gears (Fig. D)

 Never switch gears when the motor is
running, this will damage your machine.

 Never put switch in the middle between
both positions, this will damage your
machine.

The machine has 2 drill speeds, which can be
adjusted by sliding the gear switch (8) forward or
backwards. The number on the gear switch (8)
shows which position is chosen.
