7

EN

b)

   Children being supervised not to play with

the appliance

c)   Do not recharging non-rechargeable batteries!
d)   During charging, batteries must be placed in

the well ventilated area!

Residual risks

Even when the power tool is used as
prescribed it is not possible to eliminate all
residual risk factors. The following hazards
may arise in connection with the power tool’s
construction and design:

a)   Health defects resulting from vibration

emission if the power tool is being used
over longer period of time or not adequately
managed and properly maintained.

b)   Injuries and damage to property to due to

broken accessories that are suddenly dashed.

Warning!

 This power tool produces an

electromagnetic field during operation.
This field may under some
circumstances interfere with active or
passive medical implants. To reduce the
risk of serious or fatal injury, we
recommend persons with medical
implants to consult their physician and
the medical implant manufacturer before
operating this power tool.

2.  MACHINE INFORMATION

Intended use

This cordless drill is intended for driving in and
loosening screws as well as for drilling in wood,
metal and plastic.

Technical specifications

Model No

CDM1164

Voltage 20V

Chuck capacity

0.8 - 10mm

Torque settings

17 + Drill mode

No load speed

  Position 1:

0-350 /min

  Position 2:

0-1300 /min

Weight

0.8 kg

Sound pressure level L

PA

70.3 dB(A), K=5dB(A)

Sound power level L

WA

81.3 dB(A), K=5dB(A)

Vibration

2.368 m/s

2

 k=1.5m/s

2

Model No

CDA1167

Battery Type

Lithium-Ion

Voltage 20V

Capacity

2.0 Ah

Recommended charger

CDA1169, CDA1170

Weight

0.3 kg

Model No

CDA1169

Charger input

100-240V~ 50/60Hz Max 1A

Charger output

21.5

 1.7A

Rechargeable battery pack

20V Li-ion 1.5Ah

Charging time 2.0Ah battery

90 minutes

Charging time 4.0Ah battery

120 minutes

Recomended batteries

CDA1167, CDA1168

Weigth

0.15 kg

Only use the following batteries of the FX-POWER
20V battery platform. Using any other batteries
could cause serious injury or damage the tool.
CDA1167   20V, 2Ah Lithium-Ion (Included)
CDA1168   20V, 4Ah Lithium-Ion

The following charger of the can be used to
charge these batteries.
CDA1169   Charger adapter (Included)
CDA1170   Quick charger

The batteries of the FX-POWER 20V battery
platform are interchangeable with all the FERM
FX-POWER battery platform tools.

Vibration level

The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardized test given in
EN 62841; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned.
•   Using the tool for different applications, or with

different or poorly maintained accessories,
may significantly increase the exposure level.

•   The times when the tool is switched off or when

it is running but not actually doing the job, may
significantly reduce the exposure level.

Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns.
