E N G L I S H

26

KEYLESS CHUCK INSTALLATION (FIG. 6)

Screw the chuck on by hand as far as it will go.
Tighten the chuck around the shorter end of a hex
key (not supplied) and strike the longer end in the
clockwise direction with a soft hammer.

OPERATION

Instructions for Use

  WARNING:

Always observe the safety

instructions and applicable regulations.

Trigger Switch (fi g. 1)

To start the drill, depress the trigger switch; to stop
the drill, release the trigger switch.

NOTE:

Use lower speeds for starting holes without

a center punch, drilling in metal or plastics, driving
screws or drilling ceramics. Higher speeds are better
for drilling wood and composition boards and using
abrasive and polishing accessories.

VARIABLE SPEED

A variable speed trigger switch (a) permits speed
control—the farther the trigger is depressed, the
higher the speed of the drill.

For continuous operation, press and hold the
variable speed switch, move the lock-on button (b)
up, then release the switch.

To stop continuous operation, press the switch
briefly and release it. Always switch the tool off when
work is finished and before unplugging.

Speed Dial (fi g. 1)

DWD014, DWD014S

To reduce the speed, turn the speed dial (g)
counterclockwise. To increase speed, turn the dial
clockwise.

Proper Hand Position (fi g. 7)

WARNING:

To reduce the risk of

serious personal injury,

ALWAYS

use proper hand position as shown
in figure 7.

WARNING:

 To reduce the risk of

serious personal injury,

ALWAYS

 hold

securely in anticipation of a sudden
reaction.

Proper hand position requires one hand under the
the housing, with the other hand on the main handle
(h).

Drilling

  WARNING: To reduce the risk

of serious personal injury, turn
tool off and disconnect tool from
power source before making any
adjustments or removing/installing
attachments or accessories.

  WARNING:

To reduce the risk of

personal injury,

ALWAYS ensure

workpiece is anchored or clamped
firmly. If drilling thin material, use a wood
“back-up” block to prevent damage to
the material.

  1.  Use sharp drill bits only. For WOOD, use the

low speed setting and twist drill bits, spade bits,
power auger bits, or hole saws. For METAL, use
the low speed setting and steel twist drill bits or
hole saws.

  2.  Always apply pressure in a straight line with the

bit. Use enough pressure to keep drill biting, but
do not push hard enough to stall the motor or
deflect the bit.

  3.  Hold tool firmly with both hands to control the

twisting action of the drill.

  CAUTION:

Drill may stall if overloaded

causing a sudden twist. Always expect
the stall. Grip the drill firmly to control
the twisting action and avoid injury.

 4.

  IF DRILL STALLS

, it is usually because

it is being overloaded or improperly used.

RELEASE TRIGGER IMMEDIATELY

, remove

drill bit from work, and determine cause of
stalling.

DO NOT CLICK TRIGGER ON

AND OFF IN AN ATTEMPT TO START A
STALLED DRILL — THIS CAN DAMAGE
THE DRILL

.

  5.  To minimize stalling or breaking through the

material, reduce pressure on drill and ease the
bit through the last fractional part of the hole.

  6.  Keep the motor running when pulling the bit

back out of a drilled hole. This will help prevent
jamming.

  7.  With variable speed drills there is no need to

center punch the point to be drilled. Use a
slow speed to start the hole and accelerate by
squeezing the trigger harder when the hole is
deep enough to drill without the bit skipping out.

DRILLING IN METAL

Start drilling with slow speed and increase to full
power while applying firm pressure on the tool.
A smooth even flow of metal chips indicates the
proper drilling rate. Use a cutting lubricant when
