E N G L I S H

25

Mains Plug Replacement
(U.K. & Ireland Only)

If a new mains plug needs to be fitted:

  •  Safely dispose of the old plug.

  •  Connect the brown lead to the live terminal in

the plug.

  •  Connect the blue lead to the neutral terminal.

WARNING:

No connection is to be

made to the earth terminal.

Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 13 A.

Using an Extension Cable

If an extension cable is required, use an approved
extension cable suitable for the power input of this
tool (see technical data).

The minimum conductor size is 1.5 mm

2

.

When using a cable reel, always unwind the cable
completely.

ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of
injury, turn unit off and disconnect
machine from power source

before

installing and removing accessories,
before adjusting or changing set-
ups or when making repairs.

 Be sure

the trigger switch is in the OFF position.
An accidental start-up can cause injury.

Forward/Reverse Lever (fi g. 1)

The forward/reverse lever (c) is used for withdrawing
bits from tight holes and removing screws. It is
located above the trigger switch.

To reverse the motor, release the trigger switch
FIRST and then push the lever to the right (viewed
when holding the drill in the operating position).

After any reversing operations, return lever to
forward position.

Keyed Chuck (fi g. 1, 2, 3)

DWD010, DWD014

The DWD010 and the DWD014 feature a keyed
chuck (d).

TO INSERT A DRILL BIT OR OTHER ACCESSORY

  1.  Open the chuck jaws by turning collar by hand

and insert the shank of the bit about 19 mm
(3/4") into chuck. Tighten the chuck collar by
hand.

  2.  Place chuck key in each of the three holes, and

tighten in clockwise direction. It’s important to
tighten chuck with all three holes.

To release the bit, turn the chuck counterclockwise
in just one hole, then loosen the chuck by hand.

REMOVAL OF KEYED CHUCK (FIG. 2)

Tighten the chuck around the shorter end of a hex
key. Using a soft hammer, strike the key sharply in
the counterclockwise direction when viewed from
the front of the tool. This will loosen the chuck so
that it can be removed by hand.

KEYED CHUCK INSTALLATION (FIG. 3)

Screw the chuck on by hand as far as it will go.
Insert the shorter end of a hex key and strike it in the
clockwise direction with a soft hammer.

Keyless Chuck (fi g. 1, 4–6)

DWD014S

The DWD014S features a keyless chuck (d) for
greater convenience.

TO INSERT A DRILL BIT OR OTHER ACCESSORY

  1.  Grasp the rear half of the chuck with one hand

and use your other hand to rotate the front half
counterclockwise, as shown in Figure 4. Rotate
far enough so that the chuck opens sufficiently
to accept the desired accessory.

  2.  Insert the bit or other accessory about 19 mm

(3/4") into the chuck and tighten securely by
holding the rear half of the chuck and rotating
the front portion in the clockwise direction.
When the chuck is nearly tightened, you
will hear a clicking sound. After 4–6 clicks,
the chuck is securely tightened around the
accessory.

  3.  To release the accessory, repeat step 1 listed

above.

   WARNING:

Do not attempt to tighten

drill bits (or any other accessory) by
gripping the front part of the chuck
and turning the tool on. Damage to the
chuck and personal injury may result.

KEYLESS CHUCK REMOVAL (FIG. 5)

Tighten the chuck around the shorter end of a hex
key (not supplied). Using a soft hammer or piece of
wood, strike the longer end in the counterclockwise
direction. This will loosen the chuck so that it can be
unscrewed by hand.
