English

3

WARNING:

 To reduce the risk of injury, read the

instruction manual.

Definitions: Safety Guidelines

The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
these symbols.

DANGER:

Indicates an imminently hazardous

situation which, if not avoided,

will

 result in

death or

serious injury

.

WARNING:

 Indicates a potentially hazardous situation

which, if not avoided,

could

 result in

death or

serious injury

.

EC-Declaration of Conformity

Machinery Directive

Sub-Compact Drill/Driver/Hammerdrill
DCD701,  DCD706

D

e

WALT

 declares that these products described under

Technical Data

 are in compliance with:

2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-1:2010.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact

D

e

WALT

 at

the following address or refer to the back of the manual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of

D

e

WALT

.

Markus Rompel
Vice-President Engineering, PTE-Europe

D

e

WALT

, Richard-Klinger-Straße 11,

D-65510, Idstein, Germany
06.17.2019

accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure
level over the total working period.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
work patterns.

The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN60745 and may be used to
compare one tool with another. It may be used for a preliminary
assessment of exposure.

WARNING:

 The declared vibration and/or noise emission

level represents the main applications of the tool. However
if the tool is used for different applications, with different

DCD701

DCD706

Voltage

V

DC

12

12

Type

1

1

Battery type

Li-Ion

Li-Ion

Power output

W

250

250

No-load speed


1st gear

min

-1

0–425

0–425

2nd gear

min

-1

0–1500

0–1500

Beats per minute


1st gear

-

0–7225

2nd gear

-

0–25500

Max. Torque (hard/soft)

Nm

57.5/25.5

57.5/25.5

Chuck capacity

mm

10

10

Maximum

drilling

capacity

 Wood
 Metal
 Masonary

mm
mm
mm

20
10

-

20
10
10

Weight (without battery pack)

kg

0.87

0.96

Noise values and/or vibration values (triax vector sum) according to
EN60745-2-1:

L

PA

   (emission sound pressure level) dB(A)

72

83

L

WA

   (sound power level)

dB(A)

83

94

K   (uncertainty for the given

sound level)

dB(A)

3

3

Drilling into metal

Vibration emission value a

h,D

 =

m/s

2

2.5

3.1

Uncertainty K =

m/s

2

1.5

1.5

Drilling into concrete

Vibration emission value a

h,ID

 =

m/s

2

-

15.5

Uncertainty K =

m/s

2

-

4

Screwdriving

Vibration emission value a

h

 =

m/s

2

< 2.5

<2.5

Uncertainty K =

m/s

2

1.5

1.5

English (original instructions)

Congratulations!

You have chosen a

D

e

WALT

 tool. Years of experience, thorough

product development and innovation make

D

e

WALT

 one of the

most reliable partners for professional power tool users.

Technical Data

SUB-COMPACT DRILL/DRIVER/HAMMERDRILL
DCD701,  DCD706
