10

English

Proper Hand Position (Fig. F)

WARNING:

To reduce the risk of serious personal injury,

ALWAYS

 use proper hand position as shown.

WARNING:

 To reduce the risk of serious personal

injury,

ALWAYS

 hold securely in anticipation of a

sudden reaction.

driven. To lock the clutch for drilling operations, move to the
max position.

Quick‑Release Chuck (Fig. A, E)

nOTE:

The quick‑release chuck

 4

 accepts 6.35 mm hex

accessories. Using 25 mm bits allows better access in
tight spaces.
Place the forward/reverse button

 2

 in the locked off (centre)

position or remove battery pack before changing accessories.
The bit shown in Figure E is typical of the bits for use in the
quick‑release chuck

 4

 with a groove

 14

 which is required to

hold the bit firmly.

To install an accessory

, push accessory to fully insert into the

quick‑release chuck

 4

. The quick release chuck collar

 9

 does

not need to be pulled up to lock accessory in place.

To remove an accessory

, pull the quick release chuck collar

 9

away from the front of the tool. Remove the accessory and
release the collar.

Screwdriver Mode (Fig. A)

Select the desired clutch setting using the torque adjustment
collar

 3

 on the top of tool.

Insert the desired fastener accessory into the chuck as you
would any screwdriver bit. Make a few practice runs in scrap
or unseen areas to determine the proper position of the
clutch collar.

Drilling Mode

WARNING: To reduce the risk of serious personal
injury, place the forward/reverse button in the
lock‑off position or turn tool off and disconnect
battery pack before making any adjustments or
removing/installing attachments or accessories.

WARNING:

To reduce the risk of personal injury,

 ALWAYS

ensure workpiece is anchored or clamped firmly. If drilling
thin material, use a wood “back‑up” block to prevent
damage to the material.

Turn the collar to the max position symbol for drilling.

1.  Use hex shank drill bits only.
2.  Always apply pressure in a straight line with the bit. Use

enough pressure to keep the bit biting, but do not push
hard enough to stall the motor or deflect the bit.

3.  Hold tool firmly with both hands to control the twisting

action of the tool.

WARNING:

 The screwdriver may stall if overloaded

causing a sudden twist. Always expect the stall. Grip the
screwdriver firmly with both hands to control the twisting
action and avoid injury.

4.  If the screwdriver stalls, it is usually because it is being

overloaded or improperly used. RELEASE TRIGGER
IMMEDIATELY, remove bit from work, and determine the
cause of stalling.

DO nOT CYClE TRiggER On AnD OFF

in ATTEMPT TO REsTART A sTAllED TOOl — This CAn
DAMAgE ThE TOOl.

Proper hand position requires one hand on the main handle

 5

.

Variable Speed Trigger Switch (Fig. A)

To turn the tool on, squeeze the trigger switch

 1

. To turn the

tool off, release the trigger switch. Your tool is equipped with
a brake. The chuck will stop as soon as the trigger switch is
fully released.
The variable speed switch enables you to start the application at
a slow speed. The further you squeeze the trigger, the faster the
tool will operate. For maximum tool life, use variable speed only
for starting holes or fasteners.

nOTE:

Continuous use in variable speed range is not

recommended. It may damage the switch and should
be avoided.

Forward/Reverse Control Button (Fig. A)

A forward/reverse control button

 2

 determines the direction of

the tool and also serves as a lock‑off button.
To select forward rotation, release the trigger switch and
depress the forward/reverse control button on the right side of
the tool.
To select reverse, depress the forward/reverse control button on
the left side of the tool. The center position of the control button
locks the tool in the off position. When changing the position of
the control button, be sure the trigger is released.

nOTE:

 The first time the tool is run after changing the direction

of rotation, you may hear a click on start up. This is normal and
does not indicate a problem.

Worklights (Fig. A)

There are three worklights

 8

 located around the quick‑release

chuck collar

 9

. The worklight will be activated when the

variable speed trigger switch is squeezed.
When the trigger is released, the worklight will stay illuminated
for up to 20 seconds. If the trigger switch remains depressed,
the worklights will remain on.

nOTE:

The worklight is for lighting the immediate work surface

and is not intended to be used as a flashlight.

Torque Adjustment Collar (Fig. A)

The torque adjustment collar

 3

 is clearly marked with numbers

and the max position.The collar should be rotated until the
desired setting is located at the top of the tool. Locators are
provided in the collar to eliminate the guess work when
selecting fastening torque. The higher the number on the collar,
the higher the torque and the larger the fastener which can be

installing attachments or accessories.

An accidental

start‑up can cause injury.
