12

ENGLISH

WARNING: To reduce the risk of serious personal
injury,

ensure the screw holding the belt hook is secure.

IMPORTANT:

When attaching or replacing a belt hook, use only

the screw that is provided. Be sure to securely tighten the screw.

A belt hook

 11

 can be be attached to either side of the tool

using only the screw

 12

 provided, to accommodate left- or

right-handed users. If the belt hook is not desired at all, it can be
removed from the tool.

To move the belt hook, remove the screw

 12

 that holds it in

place then reassemble on the opposite side. Be sure to securely
tighten the screw.

Installing a Bit or Accessory into
a Keyless Chuck (Fig. D)

WARNING:

 Do not attempt to tighten drill bits (or

any other accessory) by gripping the front part of the
chuck and turning the tool on. Damage to the chuck
and personal injury may result. Always lock off trigger
switch and disconnect tool from power source when
changing acces sories.

WARNING:

 Always ensure the bit is secure before starting

the tool. A loose bit may eject from tool causing possible
personal injury.

Your tool features a keyless chuck

 10

 with one rotating sleeve

 9

for one-handed operation of the chuck. To insert a drill bit or
other accessory, follow these steps.

1.  Turn tool off and remove battery pack.

2.  Grasp the black sleeve of the chuck with one hand

and use the other hand to secure the tool. Rotate the
sleeve counterclockwise far enough to accept the
desired accessory.

3.  Insert the accessory about 19 mm into the chuck and

tighten securely by rotating the chuck sleeve clockwise with
one hand while holding the tool with the other. Your tool is
equipped with an automatic spindle lock mechanism. This
allows you to open and close the chuck with one hand.

Be sure to tighten chuck with one hand on the chuck sleeve and
one hand holding the tool for maximum tightness.

To release the accessory, repeat steps 1 and 2 above.

Speed Selection (Fig. A)

The tool features two speed settings for greater versatility.

NOTE:

Do not change speeds when the tool is running.

Always allow the tool to come to a complete stop before
changing speed.

1.  To select speed 1 (high torque setting), turn the tool off and

permit it to stop. Slide the speed selector

 7

 back (away

from the chuck).

2.  To select speed 2 (high speed setting), turn the tool off and

permit it to stop. Slide the speed selector

 7

 forward (toward

the chuck).

If the tool does not change speeds, confirm that the speed
selection switch is completely engaged in the forward or
back position.

Mode Selection (Fig. A)

The mode selection collar

 6

 can be used to select the correct

operating mode depending upon the planned application.

To select, rotate the collar until the desired symbol aligns with
the arrow.

Symbol

Mode

Drilling

1–15

Screwdriving (higher number = greater torque)

Variable Speed Trigger and Forward/Reverse
Control Button (Fig. A)

The drill is turned on and off by pulling and releasing the
variable speed trigger

 4

. The farther the trigger is depressed,

the higher the speed of the drill. Your tool is equipped with
a brake. The chuck will stop as soon as the trigger switch is
fully released.
A forward/reverse control button

 5

 determines the rotational

direction of the tool and also serves as a lock-off button.
•

To select forward rotation, release the trigger and depress
the forward/reverse control button on the right side of
the tool.

•

To select reverse, depress the forward/reverse control button
on the left side of the tool.

NOTE:

 The centre position of the control button locks the tool

in the off position. When changing the position of the control
button, be sure the trigger is released.

NOTE:

 Continuous use in variable speed range is not

recommended. It may damage the switch and should
be avoided.

NOTE:

 The first time the tool is run after changing the direction

of rotation, you may hear a click on start up. This is normal and
does not indicate a problem.

OPERATION

Instructions for Use

WARNING:

Always observe the safety instructions and

applicable regulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.

An accidental

start-up can cause injury.

Proper Hand Position (Fig. E)

WARNING:

To reduce the risk of serious personal injury,

ALWAYS

 use proper hand position as shown.

WARNING:

 To reduce the risk of serious personal

injury,

ALWAYS

 hold securely in anticipation of

a sudden reaction.

Proper hand position requires one hand on the main handle

 3

and one hand on the battery pack.
