11

ENGLISH

1   Li-Ion battery pack (C1, D1, L1 models)

2   Li-Ion battery packs (C2, D2, L2 models)

3   Li-Ion battery packs (C3, D3, L3 models)

1

Instruction

manual

NOTE:

 Battery packs, chargers and kitboxes are not included

with N models. Battery packs and chargers are not included with
NT models.

NOTE:

 Trademarks and trade names are those of their

respective owners.

•

Check for damage to the tool, parts or accessories which may
have occurred during transport.

•

Take the time to thoroughly read and understand this manual
prior to operation.

Markings on Tool

The following pictograms are shown on the tool:

Read instruction manual before use.

Wear ear protection.

Wear eye protection.

Visible radiation. Do not stare into light.

Date Code Position (Fig. A)

The date code

 13

, which also includes

the year of manufacture,

is printed into the housing.

Example:

2019 XX XX

Year of Manufacture

Description (Fig. A)

WARNING:

Never modify the power tool or any part of it.

Damage or personal injury could result.

1

Battery pack

2

Battery pack release button

3

Main handle

4

Variable speed trigger

5

Forward/reverse control button

6

Mode selection collar

7

Speed selector

8

Worklight

9

Chuck sleeve

10

Keyless chuck

Intended Use

This drill/driver is designed for professional drilling and
screwdriving applications.

DO NOT

use under wet conditions or in the presence of

flammable liquids or gases.

This drill/driver is a professional power tool.

DO NOT

 let children come into contact with the tool.

Supervision is required when inexperienced operators use
this tool.

•

Young children and the infirm.

 This appliance is not

intended for use by young children or infirm persons
without supervision.

•

This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with this product.

ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.

An accidental

start-up can cause injury.

WARNING:

Use only D

E

WALT     battery  packs  and chargers.

Inserting and Removing the Battery Pack
from the Tool (Fig. B)

NOTE:

 Make sure your battery pack

 1

 is fully charged.

To Install the Battery Pack into the Tool Handle

1.  Align the battery pack

 1

 with the rails inside the

tool’s handle (Fig. B).

2.  Slide it into the handle until the battery pack is firmly seated

in the tool and ensure that you hear the lock snap into place.

To Remove the Battery Pack from the Tool

1.  Press the release button

 2

 and firmly pull the battery pack

out of the tool handle.

2.  Insert battery pack into the charger as described in the

charger section of this manual.

Fuel Gauge Battery Packs (Fig. B)

Some D

E

WALT    battery packs include a fuel gauge which consists

of three green LED lights that indicate the level of charge
remaining in the battery pack.

To actuate the fuel gauge, press and hold the fuel gauge
button

 14

. A combination of the three green LED lights will

illuminate designating the level of charge left. When the level of
charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to be recharged.

NOTE:

The fuel gauge is only an indication of the charge left on

the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-user application.

Belt Hook (Fig. C)

Optional Accessories

WARNING: To reduce the risk of serious personal
injury, DO NOT

suspend tool overhead or suspend objects

from the belt hook.

ONLY

 hang tool’s belt hook from

a work belt.
