 English |

15

Bosch Power Tools

2 609 141 290 | (16.6.15)

nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2009/125/EC (Regulation
1194/2012), 2011/65/EU, until 19 April 2016:
2004/108/EC, from 20 April 2016 on: 2014/30/EU,
2006/42/EC including their amendments and complies with
the following standards: EN 60745-1, EN 60745-2-2.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 16.06.2015

Assembly

Removing the Battery (see figure A)



Use only the battery chargers listed on the accessories
page.

Only these battery chargers are matched to the lith-

ium-ion battery of your power tool.

Note:

The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.
The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.
The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.



Do not continue to press the On/Off switch after the
machine has been automatically switched off.

The bat-

tery can be damaged.

To remove the battery

8

 press the unlocking buttons

7

 and

pull out the battery downwards.

Do not exert any force.

Observe the notes for disposal.

Changing the Tool



Before any work on the machine itself (e. g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.

There is danger of injury when unintentionally actuating
the On/Off switch.



Regularly clean the power tool’s air vents.

The motor’s

fan will draw the dust inside the housing and excessive ac-
cumulation of powdered metal may cause electrical haz-
ards.

GDR 10,8 V-EC:
Inserting (see figure B)

Pull the locking sleeve

2

 forward, push the insert tool to the

stop into the tool holder

1

 and release the locking sleeve

2

 to

lock the insert tool.

Screwdriver bits

15

 can be inserted using a universal bit hold-

er with ball lock

14

.

Removing

Pull the locking sleeve

2

 forward and remove the insert tool.

GDS 10,8 V-EC: (see figure C)



When working with an application tool, pay attention
that the application tool is connected securely on the
tool holder.

When the application tool is not securely con-

nected with the tool holder, it can come off during applica-
tion.

Slide the application tool

16

 onto the square drive of the tool

holder

1

.

With this system, there will be a slight amount of play around
the application tool

16

 after connecting securely to the tool

holder

1

; this has no influence on the function/safety.

Operation

Method of Operation

The tool holder

1

 with the tool is driven by an electric motor

via a gear and impact mechanism.

The working procedure is divided into two phases:

Screwing in

 and

tightening

 (impact mechanism in action).

The impact mechanism is activated as soon as the screwed
connection runs tight and thus load is put on the motor. In this
instance, the impact mechanism converts the power of the
motor to steady rotary impacts. When loosening screws or
nuts, the process is reversed.

Starting Operation

Inserting the battery

Set the rotational direction switch

9

 to the centre position to

protect the power tool against accidental starting.

Insert the charged battery

8

 from the front into the base of the

power tool until the battery is securely locked.

Reversing the rotational direction (see figure D)

The rotational direction switch

9

 is used to reverse the rota-

tional direction of the machine. However, this is not possible
with the On/Off switch

10

 actuated.

Right rotation:

 For driving in screws and tightening nuts,

press the rotational direction switch

9

 through to the left

stop.

Left Rotation:

 For loosening and unscrewing screws and

nuts, press the rotational direction switch

9

 through to the

right stop.

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
