14
| English
2 609 141 290 | (16.6.15)
Bosch Power Tools
Intended Use
The machine is intended for driving in and loosening screws
and bolts as well as for tightening and loosening nuts within
the respective range of dimension.
The light of this power tool is intended to illuminate the power
tool’s direct area of working operation and is not suitable for
household room illumination.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1
Tool holder
2
Locking sleeve
3
“PowerLight”
4
“PowerLight” button
5
Speed indication
6
Button for electronic speed preselection
7
Battery unlocking button
8
Battery pack
9
Rotational direction switch
10
On/Off switch
11
Battery charge-control indicator
12
Handle (insulated gripping surface)
13
Double bit *
14
Universal bit holder *
15
Screwdriver bit *
16
Application tool (e. g. an impact socket) *
17
Belt clip *
18
Colour clip *
* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Noise/Vibration Information
Sound emission values determined according to
EN 60745-2-2.
Typically the A-weighted noise levels of the product are:
Sound pressure level 87 dB(A); Sound power level 98 dB(A).
Uncertainty K = 3 dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745-2-2:
Impact tightening of fasteners of the maximum capacity of the
tool: a
h
=10.5 m/s
2
, K = 1.5 m/s
2
.
The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
Cordless Impact Screwdriver
GDR 10,8 V-EC
GDS 10,8 V-EC
Article number
3 601 JE0 0..
3 601 JE0 1..
Rated voltage
V=
10.8
10.8
No-load speed
– Setting 1
– Setting 2
min
-1
min
-1
0 – 1 200
0 – 2 600
0 – 1 200
0 – 2 600
Impact rate
– Setting 1
– Setting 2
min
-1
min
-1
0 – 2 700
0 – 3 100
0 – 2 700
0 – 3 100
Maximum torque, hard screwdriving application ac-
cording to ISO 5393
Nm
110
115
Bolt size
mm
M4 – M12
M4 – M12
Max. screw dia.
mm
8
8
Tool holder
¼" hexagon socket
3/8"
Weight according to EPTA-Procedure 01/2003
kg
0.9
0.9
Permitted ambient temperature
– during charging
– during operation
*
and during storage
° C
° C
0 ... + 45
– 20 ... + 50
0 ... + 45
– 20 ... + 50
Recommended batteries
GBA 10,8 V ...
GBA 10,8 V ...
Recommended chargers
AL 11..
AL 11..
* Limited performance at temperatures < 0 ° C
