ENGLISH

(Original instructions)

•  If the clutch ratchets before the desired

result is achieved, increase the collar

setting and continue tightening the

screw. Repeat until you reach the correct

setting. Use this setting for the remaining

screws.

Keyless chuck (fig. D)

To insert a drill bit or other accessory:

•  Grasp the rear half of the chuck (4a) with

one hand and use your other hand to

rotate the front half (4) in the

counterclockwise direction, as viewed

from the chuck end.

•  Insert the bit or other accessory fully into

the chuck, and tighten securely by

holding the rear half of the chuck and

rotating the front portion in the

clockwise direction as viewed from the

chuck end.

Warning

! Do not attempt to tighten drill bits

(or any other accessory) by gripping the

front part of the chuck and turning the tool

on. Damage to the chuck and personal

injury may occur when changing

accessories.

Dual range gearing (Figure F)

The dual range feature of your drill allows

you to shift gears for greater versatility. To

select low speed, high torque setting

(position 1), turn tool off and permit to stop.

Slide gear shifter button (5) away from the

chuck. To select the high speed, low torque

setting (position 2), turn tool off and permit

to stop. Slide gear shifter button towards

the chuck.

Note: Do not change gears when tool is

running. If you are having trouble changing

gears, make sure that the dual range gear

button is either completely pushed forward

or completely pushed back.

Drilling/screwdriving

•  Select forward or reverse rotation using

the forward/reverse slider (2).

•  To switch the tool on, press the switch

(1). The tool speed depends on how far

you press the switch.

•  To switch the tool off, release the switch.

Hints for optimum use
Drilling

•  Use sharp drill bits only.

•  Support and secure work properly, as

instructed in the Safety Instructions.

•  Use appropriate and required safety

equipment, as instructed in the Safety

Instructions.

•  Secure and maintain work area, as

instructed in the Safety Instructions.

•  Run the drill very slowly, using light

pressure, until the hole is started enough

to keep the drill bit from slipping out of it.

•  Apply pressure in a straight line with the

bit. Use enough pressure to keep the bit

biting but not so much as to stall the

motor or deflect the bit.

•  Hold the drill firmly with two hands to

control its twisting action.

•  DO NOT CLICK THE TRIGGER OF A

STALLED DRILL OFF AND ON IN AN

ATTEMPT TO START IT. DAMAGE TO THE

DRILL CAN RESULT.

•  Minimize stalling on breakthrough by

reducing pressure and slowly drilling

through the last part of the hole.

•  Keep the motor running while pulling the

bit out of a drilled hole. This will help

reduce jamming.

•  Make sure switch turns drill on and off.

Drilling in wood

Holes in wood can be made with the same

twist drill bits used for metal or with spade

bits. These bits should be sharp and should

be pulled out frequently when drilling to

clear chips from the flutes.

Drilling in metal

Use a cutting lubricant when drilling metals.

The exceptions are cast iron and brass which

should be drilled dry. The cutting lubricants

that work best are sulfurized cutting oil or

lard oil.
