ENGLISH

8

(Original instructions)

Features

This tool includes some or all of the

following features.

1. Variable speed switch

2. Forward/reverse slider

3. Torque adjustment collar

4. Keyless chuck

5. Dual range gearing

6. LED work light

7. Battery

8. Battery release button

Assembly
Use

Warning

! Let the tool work at its own pace.

Do not overload.

Charging the battery (fig.A)

The battery needs to be charged before first

use and whenever it fails to produce

sufficient power on jobs that were easily

done before. The battery may become

warm while charging; this is normal and

does not indicate a problem.

Warning

! Do not charge the battery at

ambient temperatures below 10 °C or above

40 °C. Recommended charging

temperature: approx. 24 °C.

Note

:

The charger will not charge a battery

if the cell temperature is below

approximately 10 °C or above 40 °C.

The battery should be left in the charger

and the charger will begin to charge

automatically when the cell temperature

warms up or cools down.

•  To charge the battery, insert the USB

charger (9) into the Battery (7).

•  Plug the charger (9) into a suitable

power source and switch on.

•  Charge discharged batteries within 1

week. Battery life willn be greatly

diminished if stored in a discharged

state.

Warning

! fire Hazard. When disconnecting

the charger from the tool, be sure to unplug

the charger from the outlet first, then

disconnect the charger cord from the tool.

Fitting and removing the battery

(fig.B)

•  To fit the battery, line it up with the

receptacle on the tool. Slot the battery

into the receptacle and push up until the

battery snaps into place.

•  To remove the battery, push the release

buttons (8) while at the same time pulling

the battery out of the receptacle.

Operating Instructions
Trigger switch & reversing button

(fig.

E)

•  The drill is turned ON and OFF by pulling

and releasing the trigger switch (1). The

farther the trigger is depressed, the

higher the speed of the drill.

•  A forward/reverse control button (2)

determines the direction of the tool.

•  To select forward rotation, release the

trigger switch and depress the

forward/reverse control button to the left.

•  To select reverse, depress the

forward/reverse control button the

opposite direction.

Torque control (fig.C)

This tool is fitted with a torque adjustment

collar (3) to select the operating mode and

to set the torque for tightening screws.

Large screws and hard workpiece materials

require a higher torque setting than small

screws and soft workpiece materials.

•  For drilling in wood, metal and plastics,

set the collar to the drilling position

symbol

•   For screwdriving, set the collar to the

desired setting. If you do not yet know

the appropriate setting, proceed as

follows:

•  Set the collar to the lowest torque setting.

•  Tighten the first screw.
