ENGLISH

en

15

To clean the motor:

To prevent stone dust from

collecting inside the wall chaser, you must

occasionally clean the motor by blowing

compressed air through the air duct on the back of

the motor housing, if the machine is used for

extended periods. If possible, this process should

NOT be carried out indoors/in a confined space.

Button  (7) for adjusting the handle:

Occasionally blow compressed air through the

button (when pressed, in all 3 main handle

positions).

- Overload protection:

The electronic signal

display (4) lights up and the load speed

decreases slightly.

 The machine is overloaded.

Work with a reduced load until the electronic

signal display goes out.

- Overload protection:

The electronic signal

display (4) lights up and the load speed

decreases dramatically.

 The motor temperature

is too high! Run the machine in idling until it cools

down and the electronic signal display switches

off.

-

Metabo S-automatic safety stop: The

electronic signal display (4) lights up and the

machine SWITCHES OFF automatically.

 If the

slew rate of the current is too high (for example, if

the machine suddenly seizes or kickback occurs),

the machine switches off. Switch off the machine

at the trigger (6). Switch it on again and continue

to work as normal. Try to prevent the machine

from seizing. See section 4.2.

-

Restart protection: The electronic signal

display (4) FLASHES and the machine does

not start.

The restart protection is active. If the

mains plug is inserted with the machine switched

on, or if the current supply is restored following an

interruption, the machine does not start up. Switch

the machine off and on again.

-

When switched on, the machine accelerates

to maximum speed very quickly,

 i.e. automatic

restriction of the starting current does not work

(soft start). An electronic error exists. Other

safety-related electronic functions are no longer

available. Have the machine repaired immediately

(see 16.).

Use only genuine Metabo accessories.
If you need any accessories, check with your

dealer.

Metabo diamond cut-off wheels:

diameter 230 mm, laser-welded, suitable for dry

cutting, wheel thickness in the clamping range =

1.8 mm, bore = 22.23 mm, for wall chaser MFE 65
Application

Order no.

for hard and medium-hard

materials (e.g. concrete,

including reinforced concrete)

6.28134

for abrasive materials

(e.g. abrasive concrete, sandstone,

lime sand brick, aerated concrete

and similar materials)

6.28145

Repairs to electrical tools must be carried out

by qualified electricians ONLY!

If you have Metabo electrical tools that require

repairs, please contact your Metabo service centre.

For addresses see www.metabo.com.
You can download spare parts lists from

www.metabo.com.

The sanding dust generated may contain

hazardous materials: do not dispose of with the

household waste, but at a special collection point

for hazardous waste.
Observe national regulations on environmentally

compatible disposal and on the recycling of disused

machines, packaging and accessories.

Only for EU countries: Never dispose of

power tools in your household waste! In

accordance with European Guideline 2002/

96/EC on used electronic and electric equipment

and its implementation in national legal systems,

used power tools must be collected separately and

handed in for environmentally compatible recycling.

Explanation of details on page 3. Subject to

changes serving technical progress.

D

= Diameter of the diamond cut-off wheels

B

= Groove width options

T

= Adjustable depth of cut

P1

= Nominal power input

P2

= Power output

n = No-load

speed

m

= Weight without mains cable

Vibration total value (vector sum of three directions)

determined in accordance with EN 60745:

a

h

= Vibration emission level

K

h

  = Uncertainty (vibration)

The vibration emission level given in this

information sheet has been measured in

accordance with a standardised test given in EN

60745 and may be used to compare one tool with

another. It is also suitable for a provisional estimate

of the vibratory load.
The specified vibration level applies to the main

applications of the power tool. However, if the tool is

used for other applications, with different

accessories or when poorly maintained, the

vibration level may vary. An estimation of the level of

exposure to vibration should also take into account

13. Cleaning

14. Troubleshooting

15. Accessories

16. Repairs

17. Environmental Protection

18. Technical Specifications
