ENGLISH

en

14

The direction of rotation is indicated by arrows on

the cut-off wheel and guard.

- Fit the spacers (14). For groove width and spacers

required, see table on page 2.

- Fit the cut-off wheel (15).

Make sure the

direction of rotation is correct.

The direction of

rotation is indicated by arrows on the cut-off wheel

and guard.

Regardless of the groove width, all seven

spacers must always be fitted. There must be

at least one spacer between the two diamond

cut-off wheels.
- Screw on the adjusting nut (13).

- Press and hold down the locking button  (11).

- Using a 2-hole spanner, tighten the adjusting nut

(13)  (18).

Since the mounted cut-off wheels protrude

from the safety guard, store the tool by placing

it on its side, not on the rollers.

Carry out a test run:

 Position yourself and

bystanders away from the plane of the rotating

wheel and run the power tool at maximum no-load

speed for one minute.

Damaged abrasive wheels

will normally break apart during this test period.

Stop immediately if significant vibrations occur or if

other defects are noted. If such a situation occurs,

check the machine to determine the cause.

If you remove the front diamond cut-off wheel and

leave only the rear wheel on the machine, the wall

chaser is then suited for cutting through materials

(e.g. tiles).

Release the lever (1) and set the depth of cut.

Tighten the lever (1) again.
Tip: In the case of very hard concrete and cuts

deeper than 35 mm, we recommend setting the cut

in two steps to avoid overloading the machine.

Caution! Never work without a dust extraction

device. Dusts can be harmful to health!
Never work without a dust extraction device.

The motor can quickly choke on stone dust.

Use a suitable Metabo vacuum cleaner (see

section15.).

To extract stone dust generated during work with

the wall chaser, insert the suction hose 30 344 (4 m)

in the aperture of the extraction unit (3). The

bayonet catch prevents the suction hose from

coming loose while the machine is in operation.
Using a second

suction hose

30 344

 allows you to set up the extraction unit at a

distance of up to 8m from the work place.
(Suction hose not included in scope of delivery).
To connect a suction hose without a bayonet catch,

use the connection adapter provided.

Always guide the machine with both hands.
Switch on first, then guide the accessory

towards the workpiece.
The machine must not be allowed to draw in

additional dust and shavings. When switching

the machine on and off, keep it away from dust

deposits. After switching off the machine, only place

it down when the motor has come to a standstill.

Avoid inadvertent starts: always switch the

tool off when the plug is removed from the

mains socket or if there has been a power cut.

In continuous operation, the machine

continues running if it is forced out of your

hands. Therefore, always hold the machine with

both hands using the handles provided, stand in a

safe position and concentrate.

See illustration A on page 2.

Torque activation

Switching on:  Slide the lock (5) in the direction of

the arrow and press the trigger (6).

Switching off: Release the trigger (6).

Continuous operation (depending on features)

Switching on: Slide the lock (5) in the direction of the

arrow, press the trigger (6) and keep it pressed. The

machine is now switched on. Now slide the lock (5)

in the direction of the arrow once more to lock the

trigger (6) (continuous operation).

Switching off: Press the trigger (6) and release.

Only use the wall chaser with the additional

handle attached  (9)!

Once the retaining screw is released  (10), you can

adjust the handle holder in 30° steps to the relevant

working position. When the retaining screw is

tightened, the 4 fixing pins on the handle holder are

introduced into the corresponding holes.

Always hold the tool by the main handle and

additional handle, using both hands.

Position the wall chaser with the rear guide rollers

on the work surface.

Slowly move the operating machine downward until

all guide rollers are lying flat on the work surface.
Then pull the machine in the chase direction,

e.g. from top to bottom as shown in Fig. A below

(page 4) or - for horizontal chases - back towards

itself as shown in Fig, B (page 4).
Once the channel is complete, switch off the tool

and hold it steady until the wheel comes to a stop.

Never attempt to remove the cut-off wheel from

the cut while the wheel is in motion otherwise

kickback may occur.

Lay the tool on its side.

You can remove the remaining strip between the

two chases with the chase extraction chisel

provided.

8. Using the machine with only

one

 diamond cut-off wheel

9. Depth of cut

10. Extracting the stone dust

11. Switching on and off

12. Working With the Wall Chaser
