English |

25

u

The rated speed of the accessory must be at least
equal to the maximum speed marked on the power
tool.

 Accessories running faster than their rated speed

can break and fly apart.

Working advice

u

Pull the plug out of the socket before carrying out any
work on the power tool.

u

Exercise caution when cutting slots in structural walls;
see the "Information on structures" section.

u

Clamp the workpiece if it is not secure under its own
weight.

u

Do not load the power tool so heavily that it comes to a
stop.

u

If the power tool has been subjected to a heavy load,
continue to run it at no-load for several minutes to
cool down the accessory.

u

Do not use the power tool with a cut-off stand.

u

Do not touch grinding and cutting discs until they have
cooled down.

 The discs can become very hot while work-

ing.

Rough grinding

u

Never use cutting discs for rough grinding.

The best rough grinding results are achieved with a set angle
of 30° to 40°. Move the power tool back and forth with mod-
erate pressure. This will ensure that the workpiece does not
become too hot or discolour and that grooves are not
formed.

Flap Disc

With the flap disc (accessory), curved surfaces and profiles
can be worked. Flap discs have a considerably higher ser-
vice life, lower noise levels and lower sanding temperatures
than conventional sanding sheets.

Cutting Metal

u

Always use the protective guard for cutting (9) when
cutting bonded abrasives.

When carrying out abrasive cutting, use a moderate feed
that is suited to the material being machined. Do not exert
pressure on the cutting disc and do not tilt or swing the
power tool.
Do not attempt to reduce the speed of a cutting disc coming
to a stop by applying pressure from the side.

The power tool must always
work in an up-grinding mo-
tion. Otherwise, there is a
risk that it will be pushed

uncontrolled

 out of the cut.

For best results when cut-
ting profiles and rectangular
tubing, start at the smallest
cross section.

Cutting stone

u

Provide sufficient dust extraction when cutting stone.

u

Wear a dust mask.

u

The power tool may be used only for dry cutting/grind-
ing.

For best results when cutting stone, use a diamond cutting
disc.
When using the extraction guard for cutting with a guide
block

(18)

, the vacuum cleaner must be approved for vacu-

uming stone dust. Suitable vacuum cleaners are available
from Bosch.

Switch on the power tool
and position it with the
front part of the guide block
on the workpiece. Move the
power tool with a moderate
feed motion that is suited to
the material being ma-
chined.
When cutting especially
hard materials such as con-

crete with a high pebble content, the diamond cutting disc
can overheat and become damaged as a result. This is
clearly indicated by circular sparking, rotating with the dia-
mond cutting disc.
If this happens, stop cutting and allow the diamond cutting
disc to cool down by running the power tool for a short time
at maximum speed with no load.
Working noticeably slower and with circular sparking indic-
ate that the diamond cutting disc that has become dull. You
can resharpen the disc by briefly cutting into abrasive mater-
ial (e.g. lime-sand brick).

Information on structural design

Slots in load-bearing walls are subject to DIN 1053 part 1 or
country-specific regulations. These regulations must be ob-
served under all circumstances. Seek advice from the re-
sponsible structural engineer, architect or construction su-
pervisor before starting work.

Maintenance and Servicing

Maintenance and cleaning

u

Pull the plug out of the socket before carrying out any
work on the power tool.

u

To ensure safe and efficient operation, always keep
the power tool and the ventilation slots clean.

u

In extreme conditions, always use a dust extractor if
possible. Blow out ventilation slots frequently and in-
stall a residual current device (RCD) upstream.

 When

machining metals, conductive dust can settle inside the
power tool, which can affect its protective insulation.

Store and handle the accessories carefully.
In order to avoid safety hazards, if the power supply cord
needs to be replaced, this must be done by

Bosch

 or by an

after-sales service centre that is authorised to repair

Bosch

power tools.

Bosch Power Tools

1 609 92A 4FB | (15.01.2019)
