Integrated Dust Extraction with Dust Box

(see figures C1 – C4)

Before assembling the dust box

6

, pull out the plastic slider

13

. Place the dust box

6

 onto the extraction outlet

14

 and al-

low it to engage. Make sure that the plastic slider

13

 engages

in the holder

12

.

To empty the dust box

6

, press the latching levers

15

 on the

side of the dust box (

n

). Pull off the dust box toward the bot-

tom (

o

).

Before opening the dust box

6

, it is recommended to loosen

the dust from the filter element by gently striking it against a

firm support (as shown in the figure).
Grasp the dust box

6

 by the recessed grip, fold the filter ele-

ment

16

 upward and empty the dust box. Clean the thin

plates of the filter element

16

 with a soft brush.

External Dust Extraction (see figure D)

Slide the extraction adapter

17

 onto the outlet piece

14

. En-

sure that the latching levers of the extraction adapter engage.

The extraction adapter

17

 accepts a vacuum hose with a di-

ameter of 19 mm.
For removal of the extraction adapter

17

, press the latching

levers together at the rear and pull the extraction adapter off.
The vacuum cleaner must be suitable for the material being

worked.
When vacuuming dry dust that is especially detrimental to

health or carcinogenic, use a special vacuum cleaner.

Internal Dust Extraction with Dust Bag (see figure E)

For small sanding jobs, a dust bag (accessory)

19

 can be con-

nected.
Before mounting the dust bag

19

, pull out the plastic slider

13

. Slide the dust-bag sleeve firmly over the extraction outlet

14

. Pay attention that the plastic slider

13

 engages in the

holder intended for it on the dust bag

19

.

To maintain optimum dust collection, empty the dust bag

19

in good time.

Auxiliary Handle

The auxiliary handle

1

 enables convenient handling and opti-

mal distribution of power, especially at high removal rates.
Fasten the auxiliary handle

1

 with screw

2

 to the casing.

Operation

Starting Operation

f

Observe correct mains voltage! The voltage of the pow-

er source must agree with the voltage specified on the

nameplate of the machine. Power tools marked with

230 V can also be operated with 220 V.

Switching On and Off

To

start

 the machine, press the On/Off switch

4

 and keep it

pressed.
To lock the

pressed

 On/Off switch

4

, press the lock-on button

5

.

To

switch off

 the machine, release the On/Off switch

4

 or

when it is locked with the lock-on button

5

, briefly press the

On/Off switch

4

 and then release it.

Preselecting the Orbital Stroke Rate

(GEX 125 AC/GEX 150 AC)

With the thumbwheel for preselection of the orbital stroke

rate

3

, you can preselect the required orbital stroke rate, even

during operation.

The required stroke rate depends on the material and the

working conditions and can be determined through practical

testing.
The constant electronic control keeps the stroke rate almost

constant under no-load or load conditions and ensures a uni-

form working performance.
After longer periods of working at low stroke rate, allow the

machine to cool down by running it for approx. 3 minutes at

maximum stroke rate with no load.

Sanding Plate Brake

An integrated sanding plate brake reduces the stroke rate

when running at no-load so that scoring is prevented when

placing the machine onto the workpiece.
If the no-load stroke rate continuously increases over the

course of time, then the sanding plate is damaged and must

be replaced or the sanding plate brake is worn. A worn sand-

ing plate brake must be replaced by an authorised after-sales

service agent for Bosch power tools.

Working Advice

f

Before any work on the machine itself, pull the mains

plug.

f

Wait until the machine has come to a standstill before

placing it down.

Sanding Surfaces

Switch the machine on, place it with the complete sanding

surface on the surface to be worked and move the machine

with moderate pressure over the workpiece.
The removal capacity and the sanding pattern are mainly de-

termined by the selection of the sanding sheet, the preselect-

ed orbital stroke rate (GEX 125 AC/GEX 150 AC) and the ap-

plied pressure.
Only flawless sanding sheets achieve good sanding capacity

and extend the service life of the machine.
Pay attention to apply uniform sanding pressure; this increas-

es the working life of the sanding sheets.
Intensifiying the sanding pressure does not lead to an in-

crease of the sanding capacity, but to increased wear of the

machine and the sanding sheet.
A sanding sheet that has been used for metal should not be

used for other materials.
Use only original Bosch sanding accessories.

Rough Sanding

Attach a sanding sheet with coarse grain.
Apply only light pressure to the machine so that it runs at a

higher stroke rate and high material removal is achieved.

1 – 2

Low stroke rate

3 – 4

Medium stroke rate

5 – 6

High stroke rate
