English |

19

Angle grinder

GWS 9-115

GWS 9-125

GWS 9-115 S

GWS 9-125 S

– With standard auxiliary

handle

kg

1.9

1.9

1.9

1.9

Protection class

 / II

 / II

 / II

 / II

The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.

Noise/Vibration Information

Noise emission values determined according to

EN 60745-2-3

.

Typically the A-weighted noise level of the power tool are:

93

dB(A); sound power level

104

 dB(A). Uncertainty K =

3

 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 60745-2-3

:

Surface grinding (roughing):
a

h

 =

7.5

 m/s

2

, K =

1.5

 m/s

2

,

Disc sanding:
a

h

 =

7.5

 m/s

2

, K =

1.5

 m/s

2

.

The vibration level given in these instructions has been
measured in accordance with a standardised measuring pro-
cedure and may be used to compare power tools. It can also
be used for a preliminary estimation of exposure to vibra-
tion.
The stated vibration level applies to the main applications of
the power tool. However, if the power tool is used for differ-
ent applications, with different application tools or poorly
maintained, the vibration level may differ. This can signific-
antly increase the exposure to vibration over the total work-
ing period.
To estimate the exposure to vibration accurately, the times
when the tool is switched off or when it is running but not ac-
tually being used should also be taken into account. This can
significantly reduce the exposure to vibration over the total
working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping the hands warm,
and organising workflows correctly.

Fitting

Fitting Protective Equipment

u

Pull the plug out of the socket before carrying out any
work on the power tool.

Note:

If the grinding disc breaks during operation or the

holding fixtures on the protective guard/power tool become
damaged, the power tool must be sent to the after-sales ser-
vice immediately; see the "After-Sales Service and Applica-
tion Service" section for addresses.

Protective guard for grinding

Place the protective guard

(7)

 on the spindle collar. Adjust

the position of the protective guard

(7)

 to meet the require-

ments of the operation. Lock the protective guard

(7)

 by

tightening the locking screw

(8)

 using the combination

wrench

(5)

.

u

Adjust the protective guard

(7)

such that sparking in

the direction of the operator is prevented.

Note:

The coding cams on the protective guard

(7)

 ensure

that only a protective guard that is suitable for the power
tool can be fitted.

Protective guard for cutting

u

Always use the protective guard for cutting (14) when
cutting with bonded abrasives.

u

Provide sufficient dust extraction when cutting stone.

The protective guard for cutting

(14)

 is fitted in the same

way as the protective guard for grinding

(7)

.

Side handle

u

Do not operate your power tool without the side
handle

(4)

.

Screw the side handle

(4)

 on the left or right of the machine

head depending on how your are working.

Hand guard

u

Always fit the hand guard (16)

when working with the

rubber sanding plate

(17)

or with the cup brush/disc

brush/flap disc.

Attach the hand guard

(16)

 to the side handle

(4)

.

Fitting the abrasive tools

u

Pull the plug out of the socket before carrying out any
work on the power tool.

u

Do not touch grinding and cutting discs until they have
cooled down.

 The discs can become very hot while work-

ing.

Clean the grinding spindle

(6)

 and all the parts to be fitted.

Lock the grinding spindle with the spindle lock button

(1)

before clamping and releasing the abrasive tools.

u

Do not press the spindle lock button while the grind-
ing spindle is moving.

The power tool may become dam-

aged if you do this.

Grinding/cutting disc

Pay attention to the dimensions of the abrasive tools. The
diameter of the hole must match that of the mounting flange.
Do not use an adapter or reducer.
When using diamond cutting discs, ensure that the arrow in-
dicating the direction of rotation on the diamond cutting disc
matches the direction of rotation of the power tool (see the
direction of rotation arrow on the machine head).
See the graphics page for fitting instructions.
To fasten the grinding/cutting disc, screw on the clamping
nut

(11)

 and tighten with the combination wrench; see the

(see " Quick-clamping nut

 ", page 20).
