5.

IS THERE A PROBLEM WITH YOUR APPLIANCE?

According to model:

•

The charger is getting hot:

4

  This is perfectly normal. The vacuum cleaner can remain permanently connected to the charger

without any risk.

• The charger is connected but your appliance is not charging:

  - The charger is incorrectly attached to the appliance or is faulty.

4

  Check that the charger is properly connected or contact an Approved Services Centre to change

the charger.

• Your appliance stops during use:

  - Your appliance may be overheating.

4

  Stop the appliance and leave cool for at least 1 hour.

4

  If it overheats on repeated occasions, contact the Approved Services Centre.

• The appliance stopped after the charge light was flashing:

  - The appliance has run out of battery charge.

4

  Recharge the vacuum cleaner.

• The power-brush is not working properly or makes a noise:

  - The rotating brush or hose are obstructed.

4

  Stop the vacuum cleaner and clean them.

  - The brush is worn.

4

  Contact an Approved Service Centre to change the brush.

  - The belt is worn.

4

  Contact an Approved Service Centre to change the belt.

• The power-brush stops during vacuuming:

  - The safety function has been triggered.

4

  Stop the vacuum cleaner. Check that nothing is obstructing the rotation of the brush; if there is an

obstruction, remove it and clean the power-brush, then turn on the vacuum cleaner.

• Your vacuum cleaner is not vacuuming as well, is making noise, whistling:

  - The intake channel is partially blocked.

4

  Unblock it

  - The dust collector is full.



Empty it and clean it.

  - The dust collector is not properly fitted.

4

  Re-position it correctly.

  - The intake head is clogged.

4

  Remove the power-brush and clean it.

  - The protective foam filter is saturated.

4

  Clean it.

EN

RR73XX
Error

Indicator Light

Error

Designations

Error Forms

Solutions

The red indicator light

blinks twice and beeps

Failure of the left wheel

The left wheel does not

turn and is overloaded.

Please confirm that the

device's left wheel is not

covered.

The red indicator light

blinks three times and

beeps

Failure of the right wheel

The right wheel does

not turn and is over-

loaded

Please confirm that the

device's right wheel is not

covered.

The red indicator light

blinks four times and

beeps

Failure of robot lifted

The robot is lifted over 1

second.

Please clean your vacuum

sensors and put your robot

back on the ground.

The red indicator light

blinks five times and

beeps

Failure of the front wheel

The front wheel is blocked

and no longer turns.

Please confirm that the

small wheels of the front

wheel are not covered.

The red indicator light

blinks six times and

beeps

Failure of the ground

inspection

There is a problem with

the ground inspection.

Please confirm that the sen-

sor window at the bottom

of the device is not unusu-

ally concealed.

The red indicator light

blinks seven times and

beeps

Low current or battery

The battery power sup-

ply was extremely low

(but not at the recharge

voltage critical point).

Please replace the device

on the docking station to

recharge it.

The red indicator light

blinks eight times and

beeps

Failure of the front

bumper

The impact switches

on the front left and

right shells cannot be

restored.

Please check whether or not

the device's stop is normal.

The red indicator light

blinks nine times and

beeps

Failure of the main brush

The wheel of the main

brush is overloaded or

insufficiently charged.

Please confirm that no for-

eign bodies are present on

the device's main brush.

The red indicator light

blinks ten times and

beeps

Failure of the side brush

The side sweeper wheel

is overloaded or insuffi-

ciently charged.

Please confirm that ele-

ments such as hair or fabric

are not wound around the

side brush.

The red indicator light

blinks eleven times and

beeps

Failure of the wall in-

spection

There is a problem with

the wall inspection.

Please confirm that the wall

inspection clear window is

not concealed or obstructed

by hair or fabric.

The red indicator light

blinks twelve times and

beeps

Failure of the fan

The fan only turns with

significant current flow.

Please confirm that the

fan blades are not loose or

jammed by hair or fabric.

The red indicator light

blinks fourteen times

and beeps

Load failure

The device cannot be

supplied with power

or cannot indicate the

charge status.

Please confirm that the

device is connected to the

docking station.

Please keep this user manual.
