68

Vacuuming upholstery, mattress, etc.:

Open the compartment lid and take out the small nozzle.

Small nozzle

 is used for upholstery, mattress and curtains cleaning. It is

equipped with a tape for picking up threads, which enables exact picking up the
threads, fine fibres, etc. We recommend reducing suction power during such
activity.

Vacuuming gentle fabrics and rough objects:

Open the compartment lid and take out the small brush.

Small brush

 is used for vacuuming: libraries, picture frames and windows.

We recommend reducing suction power during such activity.

Vacuuming gaps, corners, cavities, etc.:

Open the compartment lid and take out the gap nozzle.

Gap nozzle

 is used for vacuuming: gaps, corners, spaces and other recesses

with difficult access.

You can place each of a/m brushes or nozzles inside the
hose handle.
In such case it is „handy” always ready for use.

„BNB” - „Brush Natural Bristle”

It is used for cleaning and polishing hard surfaces, sensitive for scratching,
i.e. wooden floor, laminate, parquet, marble, tiles, walls, coverings made of noble
materials, etc.
Gentle and soft natural bristle provides maximum vacuuming efficiency and
protects against scratching cleaned surface.

SPECIAL ACCESSORIES

 At vacuum cleaners sale desks you can buy additionally special accessories

:

Zelmer turbo brush-

It can be used with all types of ZELMER vacuum

cleaner. It is used for vacuuming carpets and fitted carpets. Use the turbo
brush according to its operation manual.

Zelmer electro brush-

You can use for ZELMER vacuum cleaners electro

brush ZELMER only. Usage of electro brush from other company can result in
vacuum cleaner damage.
 It can be used with all types of ZELMER vacuum cleaner equipped with socket
to connect it. Use the electro brush according to its operation manual. The
electro brush his especially useful for vacuuming damaged carpets. Remove
bigger particles like remains of fabrics, paper, etc., from cleaned surface to
avoid blocking rotating element.
Turbo brush and electro-brush usage significantly increases the efficiency of
removing thready dirties such as: fur, hair, threads, etc. They are especially
useful in flats, where animals are kept (cat, dog) and it is usually difficult to
remove all fur from carpets and fitted carpets.

61B

„CYKLON”FILTRATION CARTRIDGE EMPTYING

The vacuum cleaner is equipped with removable filtration cartridge, where
dirtiness accumulates. It is necessary to empty the filtration cartridge
compartment when it is full:

−

  remove the hose from the inlet,

−

  release the hook of front lid, open it,

−

  remove filtration cartridge pulling its handle up,

−

  place all filtration cartridge over dustbin (or dust bag),

−

  unbend the hook of the filtration cartridge lid and open it until it is blocked in utmost position,
