14

Cleaning and maintenance

Only service and clean the appliance when it is switched off
and the mains power plug has been disconnected.

  Please use a moist soft cloth to clean the appliance housing.

  Do not use any aggressive cleaning agents or solvents.

After vacuuming

1. AQUA filter system

Open housing cover by lifting up the cover catch.

Remove dirty water tank.

Pull the AQUA filter (9) out of the dirty water tank by means
of the grip and pour the dirty water away (for example in the
toilet).

Remove foam filter (9a). To do this pull the AQUA filter frame
slightly upwards and then fold it over to the side out of the
way.

Now thoroughly rinse the AQUA filter, foam filter, wet
filter and the dirty water tank with clear water. Do not
use any cleaning agents.

It is essential to ensure that the parts are dry before
being refitted.

The filter can be also removed for easier cleaning when dirt and
fluff have blocked the suction filter (9b); refit the suction filter after
cleaning.
Remove contamination and fluff on the suction connector.

2. HEPA filter
Your GENIUS S1 ECO AQUAFILTER is provided with a high quality
HEPA filter (11), which can be cleaned several times depending on
your needs and the type of dust found in your home.
Clean your appliance when the suction power decreases and as when
needed (at the latest every six months). Proceed as follows:

Remove the HEPA filter from the appliance and knock out the
dirt on a firm underlay.

If the filter is strongly contaminated it can also be rinsed out
with clear water (without cleaning agent) and be subsequently
cleaned by knocking out the dirt.

Do not use any brushes for cleaning. Always allow the filter
to dry out thoroughly before fitting it back into the appliance
again.

Do not damage the filter fins when cleaning the HEPA
filter.

The filter is to be replaced by a new filter should the suction power of
the appliance not be improved to a considerably extent after cleaning
the HEPA filter.

3. MKA microfilter
The MKA microfilter (16) is to be replaced every six months.
To do this press down the two plastic lugs on the blow-out cover and
fold it back.
Replace the MKA microfilter. Close the blow-out cover again.

After sucking up liquids

Empty the dirty water tank.

Clean the anti-swash insert, dirty water tank and wet filter
using clear, possibly warm water.

Check motor protection filter for contamination and if necessary
clean under flowing water or renew if necessary.

Keep the float (10b) in the dirty water tank clean and fully
functional at all times. It interrupts vacuuming when the dirty
water tank is full.

Wipe up spray water accumulating in the suction chamber with
a soft cloth.

Remove any contamination on the intake connector and on the
inside of the closing cover.

●

  The housing cover can be taken off the appliance for easier

cleaning.

  To do this open the cover and swing it down vertically. Press the

cover forwards until it slides out of the hinge. Afterwards swing the
cover upwards and out of the way.

●

  Insert the cover in the housing vertically to fasten and close it. The

cover automatically clips into the hinge.

Allow the appliance and accessory parts to dry well after cleaning.

 Further supplies /special accessories

An extensive range of special accessories and further supplies are
available for your THOMAS GENIUS S1 ECO AQUAFILTER dealer.
Get further details from your specialist dealer or by returning the
accompanying reply card to us. Further details can also be obtained
direct from the THOMAS Works Customer Service Department.

Note!

You can only assure a properly functioning appliance and efficient
cleaning by using original THOMAS accessories.

 Customer service

Ask your dealer to tell you the THOMAS Customer Service Area Cen-
tre responsible for you.

At the same time please tell your dealer the details
given on the rating plate of the THOMAS GENIUS S1
ECO AQUAFILTER:

Repairs more especially to electrical parts are only
carried out by a qualified electrician. This ensures that
your appliance remains fully functional and safe in
operation.

As a consequence, in the case of irregularities you
should get in touch with your specialist dealer.
