Thomas GENIUS S1 ECO AQUAFILTER - Инструкция по эксплуатации - Страница 15

13

 General instructions

To connect up suction hose

–  Insert the suction hose connection piece in the appliance connector

and turn backwards until it locks.

To remove suction hose

–  Press the button on the connection piece. Turn the connection piece

a quarter of a turn to the side and draw out.

Parking position

–  Hang the suction tube complete with nozzle and hose in the suction

tube holder on the back of the appliance.

-  Should the appliance be stored in the upright position hang the

suction tube on the bottom of the appliance.

Mechanical suction power control

The suction power can also be adjusted by means of the mechanical
suction power controller (auxiliary air slide).
Auxiliary air slide closed = full suction power
Auxiliary air slide open = reduced suction power.

 Dust vacuuming

Information for use

●

  Do not use the GENIUS S1 ECO AQUAFILTER for dry vacuuming

when the AQUAFILTER system has not been appropriately fitted
according to the operating instructions. This could cause damage
to the appliance.

●

  Do not suck up any liquids when dry vacuuming.

●

  Do not suck up any large quantity of fine dust, for example, cho-

colate powder, flour, etc.

To make the AQUA filter ready for use

Your GENIUS S1 ECO AQUA FILTER is set ready for dry vacuuming
at the works.


Open appliance cover by lifting up the cover catch.

Draw out the AQUA filter from the dirty water tank by means
of the grip. Fill up the dirty water tank with 1 litre of clean
water.

Insert the complete AQUA filter up to the stop behind the two
guide ribs of the dirty water tank.

At the same time make sure that the wet filter is fitted and the
circumventing AQUA filter seal is tight up against the inside of
the dirty water tank.

Connect up suction hose and fit telescopic suction tube. Connect the
required accessory.

  To achieve optimal filtration we recommend rinsing out the

AQUA filter quickly with clear water after approx. 40-60
minutes continuous operation or when a large number of
drops of water can be seen on the underside of the cover. You
should also change the water in the dirty water tank.

For hygienic reasons the AQUAFILTER system is to
be emptied and cleaned every time the appliance
is used. Dirty water and moist parts propagate the
growth of bacteria and fungi (see cleaning and main-
tenance instructions).

 To suck up liquids

Information for use

  You can suck up spilled, non-hazardous water-based liquids

(for example, water, coffee, etc.) with the THOMAS GENIUS
S1 ECO AQUAFILTER.

●

Caution!

 Petrol, thinners, heating oil, etc., can develop explosive

vapour and mixtures when mixed with the intake air.

●

  Acetone, acids and solvents can attack the materials used to

produce the appliance. Clean and dirty water can be sucked up
without any hesitation.

●

  Clean and dry the dirty water tank and all the used parts after

sucking up liquids.

●

  Never suck up liquids without the dirty water tank.

●

  Your THOMAS GENIUS S1 ECO AQUAFILTER is not suitable for

sucking up larger quantities of liquid from containers or basins.

●

  Empty and clean the appliance every time it is used for wet clea-

ning. Dirty water and moist parts propagate the growth of bacte-
ria and fungi (see cleaning and maintenance instructions).

Put the 2-piece anti-swash insert together.

Draw out the AQUA filter from the dirty water tank by the grip
and insert the anti-swash insert.

Remove the HEPA filter from the appliance.

Insert the anti-swash insert and dirty water tank in the
appliance. Make sure that both the wet filter (10a) and the
motor protection filter (12) are fitted.

Connect up suction hose.

Select a suitable nozzle and fit it on the respective suction tube or
hand grip.

Pull the mains power plug and cable out of the appliance and connect
up.

Switch on the appliance and set for maximum suction power.
Make sure that the mechanical suction power control (21) is complete-
ly closed.

To make sure that the liquid found in the suction tube does not run
back into the suction tube when not working hold the suction tube and
hose upwards at an angle for a few seconds with running motor. Only
switch off the appliance after doing this.

  The float in the dirty water tank automatically interrupts the

suction cleaning operation when the dirty water tank is full.
(You can clearly hear the motor running at a higher speed in
this case). Switch off the appliance, disconnect the mains power
supply plug and empty the dirty water tank.

GB
