 - This appliance is not intended for use by persons (including children) with reduced physical,

sensor y or mental capabilities, or lack of experience and knowledge, unless they have been given

super vision or instruction concerning use of the appliance by a person responsible for their

safety.

 - Children should be super vised to ensure that they do not play with the appliance.

 - Do not point the hose, the tube or any other accessor y at the eyes or ears nor put it in your

mouth when it is connected to the vacuum cleaner and the vacuum cleaner is switched on.

Caution

 - When you use the vacuum cleaner to vacuum ashes, fine sand, lime, cement dust and similar

substances, the pores of the dustbag become clogged. As a result, the dustbag-full indicator will

indicate that the dustbag is full. Replace the disposable dustbag or empty the reusable dustbag,

even if it is not full yet (see chapter ‘Replacing/emptying the dustbag’).

 - Never use the appliance without the motor protection filter. This could damage the motor and

shor ten the life of the appliance.

 - Only use Philips s-bag

`

 synthetic dustbags or the reusable dustbag provided (some countries

only).

 - The translucent display panel is made of recyclable polycarbonate (>PC/ABS<).

 - Noise level: Lc = 78 dB(A)

Electromagnetic fields (EMF)

This Philips appliance complies with all standards regarding electromagnetic fields (EMF). If handled

properly and according to the instructions in this user manual, the appliance is safe to use based on

scientific evidence available today.

Preparing for use

hose

  1

 To connect the hose, push it firmly into the appliance (‘click’) (Fig. 2).

  2

 To disconnect the hose, push the buttons and pull the hose out of the appliance (Fig. 3).

tri-scopic tube

  1

 To connect the tube to the handgrip, press the spring-loaded lock button on the handgrip

and insert the handgrip into the tube. Fit the spring-loaded lock button into the opening in

the tube (‘click’) (Fig. 4).

  2

 To disconnect the tube from the handgrip, press the spring-loaded lock button and pull the

handgrip out of the tube.

  3

 Adjust the tube to the length you find most comfortable during vacuuming. Press one of the

two collars downwards and pull the tube part above the collar upwards or push it

downwards (Fig. 5).

Keep the tube away from your face when you extend it. The tube is very long.

tri-active nozzle

The Tri-Active nozzle is a multi-purpose nozzle for carpets and hard floors.

 - The side brushes catch more dust and dir t at the sides of the nozzle and allow you to clean

better along furniture and other obstacles (Fig. 6).

 - The opening at the front of the nozzle allows you to vacuum larger par ticles (Fig. 7).

  1

 To connect and disconnect the Tri-Active nozzle, use the same method as for the tube.

  2

 To clean hard floors, push the rocker switch on top of the nozzle with your foot (Fig. 8).

English

7
