1.

3.

2.

4.

5.

6.

7.

8.

10.

11.

12.

13.

14.

15.

16.

17.

18.

19.

9.

20.

22.

23.

24.

26.

27.

28.

29.

30.

31.

32.

33.

34.

25.

21.

1.

2.

English

Accessories

1

Dust bag, s-bag®

2*

Telescopic tube

3*

Extension tube (2)

4

Hose handle + hose

5

Carpet/hard oor nozzle

6*

Parquet nozzle

7*

Turbo nozzle

8

Combination nozzle

Safety precautions

This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabili-
ties, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
The vacuum cleaner features double insulation and does
not need to be earthed.
Children should be supervised to ensure that they do not
play with the appliance.

Never vacuum:

In wet areas.

•

Close to ammable gases, etc.

•

Without an s-bag® (this may damage the cleaner). A

•

safety device is tted which prevents the cover to close
without an s-bag®. Do not attempt to force cover to close.
Sharp objects.

•

Fluids (this can cause serious damage to the machine).

•

Hot or cold cinders, lit cigarette butts, etc.

•

Fine dust from plaster, concrete, our or ash, for example.

•

The above can cause serious damage to the motor –

•

damage which is not covered by the warranty.

Electrical cable precautions:

If the supply cord is damaged, it must be replaced by

•

the manufacturer, it’s service agent or similary quali ed
person in order to avoid a hazard. Damage to the cleaner
cable will not be covered by the warranty.
Never pull or lift the vacuum cleaner by the cable.

•

Disconnect the plug from the wall socket before cleaning

•

or maintaining the vacuum cleaner.
Regularly check that the cable is not damaged. Never use

•

the vacuum cleaner if the cable is damaged.

All service and repairs must be carried out by an authorised
Electrolux service centre. Always keep the vacuum cleaner
in a dry place.

Before starting

(9.)

Check that the dust bag; s-bag® and motor ilter are
in place.

(10.)

Insert the hose until the catch clicks to engage
(press the catch to release the hose).

(4.)

Insert the hose in the handle until the catch clicks
to engage (press the catch to release the hose ).

(11.)

Attach the extension wand or telescopic wand
(only on certain models) to the hose handle and
oor nozzle (to take them apart again, twist and
pull).

(12.)

Extend the cord and plug it into the wall socket.
The vacuum cleaner has an integrated cord winder.
To rewind the cable press the foot pedal (take hold
of the plug to prevent it striking you).

(13.)

Start the vacuum cleaner by rotaring the power
control button.

(13./14.)  Adjust suction power using the power control but-

ton on the vacuum cleaner or the suction control
on the hose handle.

(15.)

A practical parking feature (as well as minimizing
the risk of breakage) makes things easier when
pausing during cleaning.

(16.)

The parking feature makes it easier to move and
store the vacuum cleaner.

Use the nozzles as follows:

Carpets:

 Use the carpet/hard oor nozzle with the lever in

position (17). Reduce suction power for small carpets.

Hard loors:

 Use the carpet/hard oor nozzle with the lever

in position (18).

Wooden oors:

 Use the parquet nozzle (certain models only,

6).

Special combined nozzle:

 Detach the nozzle from the ac-

cessory dock and use it for bookshelves (with folding out
of the „brush” end) or crevices, corners (with the „crevice”
end) (8.)

Using the turbo nozzle

(certain models only) (7.)

(19.)

Attach the nozzle to the tube.

Note: Do not use the power or turbo nozzle on fur rugs, rugs
with long fringes or a pile depth exceeding 15 mm. To avoid
damaging the carpet, do not keep the nozzle stationary whilst
the brush is rotating. Do not pass the nozzle across electric ca-
bles, and be sure to switch o the vacuum cleaner immediately
after use.

Replacing the s-bag®/cleaning the ilter

Changing dust bag, s-bag®

The dust bag must be replaced latest when the indicator
window is completely red. Read with the nozzle lifted up
(20.).
1.

Open the lid.

2.

Push the dust bag holder backward (21.) and close the
bag by sliding tab (22.).

3.

Lift out the dust bag (23.).

Beware: Lift out the bag carefully if it’s completely full.

4.

Insert the new dust bag from upside by pushing the
holder backward again.

5.

Before closing the lid make sure the holder is in the
forward position and the dust bag cardboard ts over
the pipe-stub.

When purchasing new dust bags, look for this symbol on the
dust bag packaging:

2
