44

* Dependent on model

Replacement parts and special accesso-

ries

A  Hard-floor nozzle BBZ123HD

For vacuuming hard floors
(parquet, tiles, terracotta, etc.)

B  Hard-floor nozzle BBZ124HD

With 2 rotating brush rollers

For caring for expensive hard floors
and for the improved collection of
coarse dir t.

Before using your appliance for the first
time

Fig.

1

 Push the handle onto the flexible hose and lock it in
place.

Initial use

Fig.

2

a)

 Push the flexible tube adapter into the air intake
opening on the appliance and lock it in place. You
will hear an audible 'click'.

b)

 To remove the flexible hose, press the two catches
together and pull out the hose.

Fig.

3*

a)

 Push the handle into the telescopic tube. To remove
it, turn the handle slightly and pull it out of the
tube.

b)

 Push the handle into the telescopic tube until it
locks into place. To release the connection, squee -
ze the collar sleeve and pull the handle out.

Fig.

4

a)

 Inser t the telescopic tube into the connecting piece
of the floor tool. To release the connection, turn the
tube slightly and pull it out of the floor tool.

b)

 Push the telescopic tube into the connecting piece
of the floor tool until it locks in place. To release
the connection, press on the locking collar and pull
out the telescopic tube.

Fig.

5*

 Unlock the telescopic tube by moving the sliding
switch in the direction of the arrow and adjust to
the desired length. The slide resistance on carpet
is at its lowest when the telescopic tube has been
completely pulled out.

Fig.

6*

a)

 Place the accessories holder in the required positi-
on on the telescopic tube.

b)

 Use some pressure to inser t the upholster y nozzle
with brush ring and the crevice nozzle into the ac-
cessories holder from above or below.

Fig.

7

Holding the power cord by the plug, pull out to the
required length and inser t the plug into the mains
socket.

Fig.

8

To switch the vacuum cleaner on or off, press the
ON/OFF button.

Fig.

9*

 Controlling the suction level

Turn the rotar y control to infinitely adjust the suction
level to the level required.

min -

For vacuuming cur tains and delicate textiles

 -   For vacuuming upholstered furniture and

cushions

 -   For vacuuming delicate rugs und for daily

vacuuming of lightly soiled floors

 -   For vacuuming durable floor coverings

ma x -

For vacuuming hard floors and heavily soiled
rugs and carpets

Vacuum cleaner with „ComfortSensor“

Fig.

10*

 Controlling the suction level

Turn the rotar y control to infinitely adjust the suction
level to the level required.

 -

For vacuuming upholstered furniture and
cushions

 -

For vacuuming delicate rugs und for daily
vacuuming of lightly soiled floors

 -

For vacuuming durable floor coverings

Comfor t -  one setting for all floors. Makes vacuuming a

breeze, whatever the floor type.

ma x -

 For vacuuming hard floors and heavily soiled
rugs and carpets

Vacuum cleaner with „autoControl“

Fig.

11*

 Controlling the suction level

Turn the rotar y control to infinitely adjust the suction
level to the level required.

min -

For vacuuming cur tains and delicate textiles

 -   For vacuuming upholstered furniture and

cushions

 -   For vacuuming delicate rugs und for daily

vacuuming of lightly soiled floors

 -   For vacuuming durable floor coverings

auto -

For vacuuming hard floors and heavily soiled
rugs and carpets
