10



Burner "MINIMUM" adjustment

:

Work surface burner adjustment: follow the instructions below to adjust the work

surface burner minimum:

-  Light the burner and set the knob to the MINIMUM position (small flame).

-  Remove the knob of the valve that is press-fit on the rod of that valve.

-  Insert a small slotted screwdriver into the hole on the valve body (Fig.10A) and

turn the choke screw to the right or left until the burner flame is adjusted to
minimum.

-  For the gas valve of dual burner the choke valve is located on the valve body

(fig. 10B) , the A screw adjust the outer  ring, the B screw adjust the inner ring.

-  Make sure that the flame does not go out when switching quickly from the

MAXIMUM to the MINIMUM position.









Fig 10A



Fig 10B



WARNING:

 The above-mentioned adjustment should be made only with natural gas

burners,  while  those operating  with  liquid gas the screw must be locked at the  end

in a clockwise direction.



Test the operation of      It should be noted that Bertazzoni SpA cannot accept any liability for direct or

the cooker before           indirect damage caused by incorrect connection or improper installation. When

leaving                           being repaired, the appliance must always be disconnected from the mains supply; if

required, notify our customer service.



Support legs                   4 support legs are supplied separately and are fitted on location to the four corners

of the lower support frame (Fig.11)

After unpacking the cooker, lift it approx 250mm to fit the legs then gently  lower the

cooker to keep undue strain from the legs. It is recommended to use a lifting device

instead of tilting the unit.

Transit  supports  are  left  in  situ.  Each  leg  is  firmly  pushed  over  one  of  the  transit

supports.  If  the  legs  are  not  used  and  the  cooker  is  mounted  onto  a  plinth,  leave

transit legs in position to allow for clearance.









Fig 11





Up-stand Installation      The up-stand is packaged at the bottom rear of the cooker. The up-stand is fixed

along the rear of the cooker hob. Screw fixing points for locating the up-stand are at

either end.

1.  Place the up-stand on the rear of the hob, line up locating holes and secure with

the screws supplied.

2.
