10

•  Never use the tool when cord is damaged; have it

replaced by a qualified person

•

Do not work materials containing asbestos

 (asbestos

is considered carcinogenic)

•  Dust from material such as paint containing lead, some

wood species, minerals and metal may be harmful

(contact with or inhalation of the dust may cause allergic

reactions and/or respiratory diseases to the operator or

bystanders);

wear a dust mask and work with a dust

extraction device when connectable

•  Certain kinds of dust are classified as carcinogenic (such

as oak and beech dust) especially in conjunction with

additives for wood conditioning;

wear a dust mask and

work with a dust extraction device when connectable

•  Follow the dust-related national requirements for the

materials you want to work with

•  Only use a saw table provided with a switch that prevents

restarting of the motor after interruption of voltage

•  Only use a saw table provided with a kerf guide

ACCESSORIES

•  SKIL can assure flawless functioning of the tool only

when original accessories are used

•  Use only accessories with an allowable speed matching

at least the highest no-load speed of the tool

•  Use only saw blades with a minimum diameter of

170 mm, a maximum diameter of 184 mm and a

spindle hole of 16 mm

•  Never use saw blades made of high speed steel (HSS)

•  Never use grinding/cutting discs with this tool

BEFORE USE

•  Always check that the supply voltage is the same as the

voltage indicated on the nameplate of the tool (tools with

a rating of 230V or 240V can also be connected to a

220V supply)

•  Avoid damage that can be caused by screws, nails and

other elements in your workpiece; remove them before

you start working

•  Remove all obstacles on top of as well as underneath the

cutting path before you start cutting

•

Secure the workpiece

 (a workpiece clamped with

clamping devices or in a vice is held more securely than

by hand)

•

Use suitable detectors to find hidden utility lines or

call the local utility company for assistance

 (contact

with electric lines can lead to fire or electrical shock;

damaging a gas line can result in an explosion;

penetrating a water pipe will cause property damage or

an electrical shock)

•  Use completely unrolled and safe extension cords with a

capacity of 16 Amps (U.K. 13 Amps)

DURING USE

•  The noise level when working can exceed 85 dB(A); wear

ear protection

•  Never use the tool without the original protection guard

system

•  Do not attempt to cut extremely small workpieces

•  Do not work overhead with the tool

•  In case of jamming or electrical or mechanical

malfunction, immediately switch off the tool and

disconnect the plug

•  If the cord is damaged or cut through while working, do

not touch the cord, but immediately disconnect the plug

AFTER USE

•  When you put away the tool, switch off the motor and

ensure that all moving parts have come to a complete

standstill

•  After switching off your circular saw, never stop the rotation

of the saw blade by a lateral force applied against it

WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):

•  Do not connect the blue (= neutral) or brown (= live) wire

in the cord of this tool to the earth terminal of the plug

•  If for any reason the old plug is cut off the cord of this tool,

it must be disposed of safely and not left unattended

USE

•  Mounting saw blade

3

!  disconnect the plug

-  take hex key A from storage B

-  push spindle-lock button C and hold it while you

remove blade bolt D with hex key

!  push spindle-lock button C only when tool is at a

standstill

-  release spindle-lock button C

-  remove flange E

-  open lower guard F with lever G and hold it while you

mount saw blade with saw teeth and arrow printed on

saw blade pointing in same direction as arrow on

upper guard

-  release lower guard F

-  mount flange E

!  make sure that clamping surfaces H of flanges

are perfectly clean and face the blade

-  push spindle-lock button C and hold it while you

tighten blade bolt with hex key 1/8 turn past finger tight

(ensures slippage of saw blade when it encounters

excessive resistance thus reducing motor overload

and saw kickback)

-  release spindle-lock button C

•  Adjusting cutting depth (0-65 mm)

4

-  for an optimal quality cut the saw blade should not

extend more than 3 mm below the workpiece

-  loosen knob J

-  raise/lower foot K until desired cutting depth is set on

scale using indicator L

-  tighten knob J

•  Adjusting cutting angle (0-45°)

5

-  loosen knob M

-  tilt tool until desired cutting angle is set on scale using

indicator N

-  tighten knob M

!  when bevel cutting, cutting depth does not

correspond with value on cutting depth scale

•  90° Cutting angle check

5

-  adjust and tighten foot K to maximum cutting depth

4

-  adjust and tighten cutting angle to 0°

-  check for a 90° angle between the blade and bottom of

foot with a square

-  if adjustment is needed, loosen knob M and use

adjustment screw P as illustrated

•  Adjustable saw line visor Q

6

a

-  for guiding tool along desired line of cut marked on the

workpiece

-  for a straight 0° cut or a 45° bevel cut use the indicator

line concerned
