9 ENGLISH

Hex wrench storage

►

Fig.17:

1.

 Hex wrench

When not in use, store the hex wrench as shown in the

figure to keep it from being lost.

Connecting a vacuum cleaner

Optional accessory

When you wish to perform clean cutting operation,

connect a Makita vacuum cleaner to your tool. Connect

a hose of the vacuum cleaner to the dust nozzle as

shown in the figure.

►

Fig.18:

1.

 Dust nozzle

2.

 Screw

►

Fig.19:

1.

 Hose

2.

 Vacuum cleaner

OPERATION

CAUTION:

Be sure to move the tool forward

in a straight line gently.

 Forcing or twisting the tool

will result in overheating the motor and dangerous

kickback, possibly causing severe injury.

►

Fig.20

Hold the tool firmly. The tool is provided with both a front

grip and rear handle. Use both to best grasp the tool.

If both hands are holding saw, they cannot be cut by

the circular saw blade. Set the base on the workpiece

to be cut without the circular saw blade making any

contact. Then turn the tool on and wait until the circular

saw blade attains full speed. Now simply move the tool

forward over the workpiece surface, keeping it flat and

advancing smoothly until the sawing is completed.

To get clean cuts, keep your sawing line straight and

your speed of advance uniform. If the cut fails to prop-

erly follow your intended cut line, do not attempt to turn

or force the tool back to the cut line. Doing so may bind

the circular saw blade and lead to dangerous kickback

and possible serious injury. Release switch, wait for cir

-

cular saw blade to stop and then withdraw tool. Realign

tool on new cut line, and start cut again. Attempt to

avoid positioning which exposes operator to chips and

wood dust being ejected from saw. Use eye protection

to help avoid injury.

Rip fence (Guide rule)

Optional accessory

►

Fig.21:

1.

 Rip fence (Guide rule)

2.

 Clamping screw

The handy rip fence allows you to do extra-accurate

straight cuts. Simply slide the rip fence up snugly

against the side of the workpiece and secure it in posi-

tion with the clamping screw on the front of the base. It

also makes repeated cuts of uniform width possible.

MAINTENANCE

CAUTION:

Always be sure that the tool is

switched off and unplugged before attempting to

perform inspection or maintenance.

CAUTION:

Clean out the guard to ensure

there is no accumulated sawdust and chips

which may impede the operation of the guarding

system.

 A dirty guarding system may limit the proper

operation which could result in serious personal

injury. The most effective way to accomplish this

cleaning is with compressed air.

If the dust is being

blown out of the guard, be sure the proper eye

and breathing protection is used.

NOTICE:

Never use gasoline, benzine, thinner,

alcohol or the like. Discoloration, deformation or

cracks may result.

Replacing carbon brushes

►

Fig.22:

1.

 Limit mark

Check the carbon brushes regularly.

Replace them when they wear down to the limit mark.

Keep the carbon brushes clean and free to slip in the

holders. Both carbon brushes should be replaced at the

same time. Use only identical carbon brushes.

1.

  Use a screwdriver to remove the brush holder

caps.

2.

  Take out the worn carbon brushes, insert the new

ones and secure the brush holder caps.

►

Fig.23:

1.

 Brush holder cap

To maintain product SAFETY and RELIABILITY,

repairs, any other maintenance or adjustment should

be performed by Makita Authorized or Factory Service

Centers, always using Makita replacement parts.
